Chapter 2 Installation
Rear View
10
The rear plate contains the On/Off switch, the AC power cord
receptacle, and various interface connectors and slots.
Intermec EasyCoder F4 – Installation & Operation IPL Version, Ed. 1
(not used)
(not used)
Provision for one IEEE1284 Parallel Inter-
face Board
On/Off Switch
AC Power Cord Receptacle
RS-232 Serial Interface Socket
Memory Card Slot (for fi rmware upgrade)
(not used)
Machine Label
