Charging; Precautions On Charging - Docomo Arrows NX F-06E Instruction Manual

Charging

❖

Precautions on charging

If you use applications while charging, it may take time to
complete charging or charging may not complete due to
drop-off of battery. It is not abnormality of the terminal.
It is normal for the terminal or AC adapter to become warm
while charging. When the terminal becomes warm, charging
may stop temporarily for the safety. When the terminal
becomes extremely hot, stop using immediately.
The following conditions will lead to a charging error and
the indicator LED turns off. Charging restarts when the
charging becomes possible.
- When the power voltage of the charger becomes out of
chargeable range
- When temperature of the internal battery or the terminal
becomes out of chargeable range
* When the temperature rises high, wait until the temperature is
dropped and then retry charging.
If charging takes for very long time, a charging error is
notified and the indicator LED turns off. Remove the
terminal from the charger and retry.
When power voltage of the internal battery is abnormal,
charging error occurs and the indicator LED flashes. Remove
the terminal from the charger, turn off the power, and then
contact "Repairs" on the last page of this manual (in
Japanese only) or DOCOMO-specified repair office.
When charging starts with the battery empty, the terminal
may not be immediately activated after turning the power
ON. In this case, charge the terminal while keeping it turned
OFF, and turn it ON after a while.
For charging time, see "Main specifications" P186
❖
Internal battery life
The internal battery is a consumable part. Each time it is
charged, time available with each charging reduces. Talking
on the phone for a long time while charging may reduce the
internal battery lifetime.
You can check performance (charging ability) of the internal
battery from About phone. P148
When a time available with each charging is reduced to
about a half from that of a new battery, replacement of the
internal battery is recommended because it is near the end
of life. For replacement of internal battery, contact "Repairs"
on the last page of this manual (in Japanese only) or
DOCOMO-specified repair office.
*
❖
Available charging adapter
For details, refer to the operation manual of AC adapter or DC
adapter.
AC Adapter 03 (optional)/AC Adapter 04 (optional)/AC
Adapter F05 (optional)/AC Adapter F06 (optional) : Between
100V and 240V AC. AC adapters have a plug dedicated to
100V AC (for domestic use). When using AC adapters in the
range of AC 100V and 240V overseas, a conversion plug
adapter applicable to the country you are staying is
required. Also, do not charge the battery with a transformer
for overseas travel.
DC Adapter 03 (optional) : Use for charging in a car.
28
Before using the terminal
