N-02D
'11.11
INSTRUCTION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the N-02D and is the answer not in the manual?

Questions and answers

Related Manuals for Docomo N-02D

Summary of Contents for Docomo N-02D

  • Page 1 N-02D ’11.11 INSTRUCTION MANUAL...
  • Page 2 Thank you for choosing "N-02D". Before use, be sure to thoroughly read this manual to ensure that you use N-02D correctly. About manual of N-02D The operations of N-02D are also described in " " (Guide) (available in this FOMA terminal) and "Instruction Manual (Detailed version)"...

  • Page 3: Table Of Contents

    Contents FOMA Terminal ......2 Style ..........6 Introduction What You Can Do with N-02D ...3 Precautions (Always follow these directions) ...7 Part Names and Functions ..4 Waterproof/Dustproof Function ...17 Before Using ......21 Sound/Screen Setting ....35 Basic Operation Screen Explanation ....25 Lock/Security ......39 p.21...

  • Page 4: Foma Terminal

    SSL/TLS. In the event that the user shall sustain damage or loss due to the use of SSL/TLS, neither DOCOMO nor the certifier shall be responsible for any damage or loss. Certifier: VeriSign Japan K.K., Cybertrust Japan Co., Ltd., GlobalSign K.K., RSA Security Japan Ltd., SECOM Trust Systems Co., Ltd., Comodo CA Ltd., Entrust, Inc.

  • Page 5: What You Can Do With N-02D

    What You Can Do with N-02D docomo Palette UI MyFACE p.29 This function lets you paste MyFACE content for displaying various information on the right and left of the standby screen. MyFACE information is updated regularly, ensuring that you always get the latest information. You can download your favorite MyFACE content easily from sites and add, sort or delete it.

  • Page 6: Part Names And Functions

    Part Names and Functions Charge lamp Earpiece Hear other party's voice from here. Multi-function keys : Up/Down key Illuminance sensor Detect brightness. Do not Move the cursor or contents etc. cover with hand or put upward or downward. sticker on it. Display the Search phonebook menu screen.
  • Page 7 GPS antenna Illumination/Charge lamp The antenna is built-in. Covering the antenna part with your hand may affect the quality. FOMA antenna The antenna is built-in. Covering the antenna part with your hand may affect the quality. Bluetooth antenna The antenna is built-in. Covering the antenna part with your hand may affect the quality.
  • Page 8 Style This FOMA terminal has three styles; folded, opened (Communication style), or folded with the display rotated outward (Touch style). Folded Communication style Touch style In this manual, operations by keys with the FOMA terminal opened (Communication style) are mainly described. Even if touch operation is available, key operations description takes priority.
  • Page 9 Precautions (Always follow these directions) To ensure that you use your FOMA terminal Indicates that it is an instruction- correctly, read "Precautions" carefully before use. based compulsory conduct (must Keep this manual after reading for future reference. be acted). The precautions must be observed at all times since they contain information intended to Indicates that you must unplug prevent the bodily injury or damage to property.
  • Page 10 Use the battery pack and adapter specified CAUTION by NTT DOCOMO for the FOMA terminal. Failure to observe this precaution may cause Do not leave the devices on a slope or fire, burns, injury or electric shock. unstable surface. The devices may fall and cause injury.
  • Page 11 Do not turn on the light near a person's eyes. If you are wearing electronic medical devices, In particular, make sure you stand at least ask the manufacturer or sales agent whether 1 m away when shooting young children. the devices can be affected by radio waves Don't before using your FOMA terminal.
  • Page 12 Do not use the damaged FOMA terminal. 3. Precautions for the Battery Pack Doing so may cause fire, burns, injury or electric shock. Don't Refer to the information shown on the battery pack label to check the type of battery. When using motion sensor, make sure you are in a safe place, hold the FOMA terminal securely, Display...
  • Page 13 (hand, finger, etc.). the terminals of used battery pack and return it to a docomo Shop or Service Counter, or Doing so may cause fire, burns or electric shock. dispose of the battery pack in accordance with your local regulations.
  • Page 14 If the fuse in the DC adapter blows, always 6. Precautions for Use Near replace it with the specified type of fuse. Electronic Medical Devices Failure to observe this precaution may cause fire, burns or electric shock. Refer to the respective According to the Guidelines on the Use of Radio manuals for the information on the specified fuse.

  • Page 15: Material List

    Material list Parts Material Coating Display Nylon resin UV coating Polycarbonate resin UV coating External chassis Rear side Aluminum Alumite coating/Aluminum foundation Key and battery pack storage Nylon resin UV coating Display panel Hardened glass Shatter-proof film, Hard coating Earpiece panel Acrylic Hard coating Display hinge...

  • Page 16: Handling Precautions

    FOMA terminal. benzene or detergents as these agents may Please be aware that DOCOMO bears no obligation or erase the printing on the FOMA terminal or responsibility in the event that data is altered or lost.
  • Page 17 UIM. In this case, please purchase a new battery pack. Please be aware that DOCOMO bears no obligation or The ambient temperature of the room should be 5 to 35 . ⿟...
  • Page 18 Concern about the If there is another reader/writer around, communication using the Bluetooth function. keep enough distance between the FOMA Please be aware that DOCOMO is not terminal and the reader/writer. Also, make ⿟ responsible for data leak when making data sure that there is no radio station using the communications using Bluetooth.
  • Page 19 *1 : IPX5 means that the N-02D continues to function as a phone after being sprayed from all directions with 12.5 liters of water per minute from a 6.3 mm diameter nozzle for at least 3 minutes, from a distance of approx. 3 meters.
  • Page 20 Opening/closing the external connector terminal cap Opening Closing Hook your finger on the slot and open the Align the tab on the back of the cap with cap in the direction of arrow. the concave of the FOMA terminal, then close the cap by pressing securely in direction of arrow.

  • Page 21: Important Notices

    FOMA terminal causing electric shock or malfunction. Stop using the FOMA terminal, turn off the power, remove the battery pack and contact a repair counter specified by DOCOMO. The external connector terminal cap and the rubber packing of the back cover play an important role in maintaining waterproof/dustproof function.
  • Page 22 Draining water when the FOMA terminal gets wet When the FOMA terminal gets wet, drain the water following the steps below. If water adheres to the mouthpiece/microphone, earpiece or speaker, the volume of the other party's voice or melody may be decreased or sound quality may deteriorate. In such a case, drain the water following the steps below and dry the FOMA terminal in open air to recover the function.

  • Page 23: Before Using

    The UIM is an IC card that contains private information such as your phone number. This FOMA terminal does not operate with a UIM (Blue) in it. If your UIM is blue, check with a docomo Shop Service Counter for replacement. Remove the back cover ( p.18)
  • Page 24 Charging For the charging time and continuous talk time, refer to "Main specifications" ( p.94). The battery pack, AC adapter and provided desktop holder are not waterproof/ dustproof. Never charge the battery with the FOMA terminal left wet. It is recommended that the desktop holder be used for charging to prevent water from seeping inside and dust from getting in through the external connector terminal.

  • Page 25: Turning Power On

    Turning power ON (1 second or longer) Standby screen If Initial setting screen appears When you turn the power on for the first time after purchase, Initial setting screen appears. To turn the power off Press for 2 seconds or longer. Configuring default setting After turning the power on for the first time after purchase, screens for initial settings such as "Auto time", "Change...

  • Page 26: Checking Your Own Phone Number

    Notifying your caller ID on the other party's phone Set whether to show your phone number (caller ID) on the other party's phone (display) when making a call. "TEL function" "Dial/Receive setting" "Caller ID notification" "Activate/Deactivate" "ON" or "OFF" If you hear a message requesting your caller ID, make a call again with Caller ID notification enabled or with 186 prefix.

  • Page 27: Screen Explanation

    Screen Explanation Viewing display/icon Symbols ( , , , etc.) displayed on the screen are referred to as icons. Icons indicate the status of such as the FOMA terminal and signal reception. Icons indicating the status of the FOMA terminal At the top of the screen, icons indicate the status of the FOMA terminal.
  • Page 28 Desktop icons and shortcut icons In the middle of the screen, desktop icons indicate the status of new arrivals. You can paste shortcut icons, with which you can launch functions. Desktop icons (examples) Missed call Record message Record VP message Voice Mail New mail Shortcut icons (examples)

  • Page 29: Osaifu-Keitai

    Viewing main menu You can select various functions of the FOMA terminal from the main menu. The main menu here is in "Standard". Mail Display the mail functions. i-mode/web Display the menus of i-mode and Full Browser. ppli Display the i- ppli menu.

  • Page 30: Key Operation

    Key operation The soft keys (Function display) corresponding to , and the direction icons corresponding to are displayed on the screen. These icons appear only when the corresponding keys can be used. Performing the functions assigned to the function key Display examples and assigned functions shows (Submenu), (Exit), (MENU), etc.

  • Page 31: Docomo Palette Ui

    When the displayed submenu contains further menu items, " " appears. docomo Palette UI You can switch from the standby screen to the MyFACE and shortcut list, and easily access various functions or services. In addition, you can freely customize this new function.
  • Page 32 Downloading MyFACE content from sites You can download MyFACE content up to approx. 600 KB from i-mode sites. Select MyFACE on a MyFACE downloadable site to select where to register the content Select "YES" or "NO" whether to automatically update the content or service You can register up to 12 MyFACE contents.

  • Page 33: Using Touchscreen

    Using Touchscreen The FOMA terminal display is a touchscreen display. Touch the screen directly with your finger to operate. Notes on use The touchscreen is designed to be touched lightly with a finger. Do not press the screen firmly with a finger or pointed objects such as fingernails, ballpoint pens, and pins. In the following cases, the touchscreen may not respond even if touched.

  • Page 34: Style

    Preventing misoperation while the FOMA terminal is in Touch style Lock the screen while the FOMA terminal is in Touch style to prevent operation. Screen lock is set and the display is blank. To deactivate the lock temporarily Press any of the side keys to turn on the display You can also unlock by opening the FOMA terminal.

  • Page 35: Character Entry

    Character Entry Entering characters When entering information to save to the phonebook, or creating mails or schedules, enter text. Switching entry modes Entering characters Converting entered text Press (Chrct) on Press a dial key several times Convert entered text to the text entry screen to enter your desired text.
  • Page 36 Let's enter text. <Example : entering " (Autumn camp)"> Enter Hiragana once twice to move the cursor to the target conversion candidate 5 times twice and then to select the candidate (Set) once once to lower case 3 times 3 times twice (Han-dakuten) Entering Deco-mail pictogram/Deco-mail picture...

  • Page 37: Sound/Screen Setting

    Sound/Screen Setting Changing ring tone Changing the ring tone for calls "Setting" "Sound/Vib./Manner" "Select ring tone" "Phone" "Select ring tone" "Melody" Select ring tone Other options such as a melody, i-motion, Chaku-Uta®, or Chaku-Uta-Full® can be set to ring tones. When i-motion is set, a video also plays.
  • Page 38 On the standby screen, (1 second or longer) appears on the standby screen. To release the setting On the standby screen, (1 second or longer) Setting keypad sound OFF "Setting" "Sound/Vib./Manner" "Other sound setting" "Keypad sound" "OFF" Changing screen setting Changing standby display "Setting"...
  • Page 39 Changing font settings On the standby screen, (1 second or longer) "Select font" Select a folder Select an item (font), then (Set) Select the thickness in "Thickness" Select a character size in "Character size" Changing Machi-chara setting Set Machi-chara, and a character appears on the standby screen to inform you of i-concier information, missed call, new mail, unread mail, etc.
  • Page 40 Select a color "Set pattern" Select a pattern You can set different flashing colors to arriving calls or mails from the specified phone numbers, mail addresses and a set of group. To set the flashing color to phonebook On Phonebook detail screen, (Submenu) "Set"...

  • Page 41: Lock/Security

    Any code is set at time of subscription A 4-digit number is required to verify your identity when you subscribe to some services at a docomo Shop, docomo Information Center and " (User support)" (in Japanese only), or when you use network services.
  • Page 42 Your PIN unblocking key (PUK) is written on application form (copy for customer), which a docomo Shop gives you at time of subscription. If you have subscribed at a retailer other than the docomo Shop, please bring your UIM and official documents that verify your identity, such as a driver's license, to a docomo Shop Service Counter, or contact "General Inquiries"...

  • Page 43: Various Lock Functions

    IC * Unavailable from part of IP phones. Lock * My docomo is also available to set/release Omakase Lock via PC, etc. (in Japanese only) card function of Osaifu- Keitai only by contacting For details on Omakase Lock, refer to "Mobile DOCOMO.
  • Page 44 Type of Lock Function Setting procedure Lock the touchscreen to To activate: "Setting" "Lock/Security" prevent misoperations Touch panel "Touch panel lock" "ON" while the FOMA terminal lock is in Touch style and after To deactivate temporarily: In Touch style and when the touchscreen the touchscreen goes off.
  • Page 45 Resetting to default Resetting the function settings to default Reset the function settings to default. For the function that can be reset, see "Menu list" ( p.90). "Initialize" and "Reset settings" are different. Do not mix them up. If you perform "Initialize", you will lose all data you have stored. "Setting"...
  • Page 46 Call Telephone Making a call/videophone call As N-02D is not equipped with the front camera, during a videophone call, you can send only the substitute image (Chara-den) or image from the rear camera to the other party. Making a call by entering the phone number...

  • Page 47: Adjusting Earpiece Volume

    To play a recorded message On the Recording notification SMS detail screen, " " (Play) "YES" Also, it can be played from: "TEL function" "Koe-no-Takuhaibin" "Message confirm (voice)" "YES". Making an international call Use WORLD CALL to make international calls from Japan. For WORLD CALL, please contact "General Inquiries"...
  • Page 48 When you can not answer a call Setting record message When you cannot answer a voice or videophone call, the FOMA terminal can record a voice or videophone message. "TEL function" "Rec. msg./Voice memo" "Record message setting" "ON" "Phone" or "Videophone" Select an item Set ring time (3-digit number between 000 and 120 seconds) If you receive a call with Record message setting ON...

  • Page 49: Select An Item

    Charged Melody call Required Charged Koe-no-Takuhaibin Not required Free For details on "OFFICEED", refer to the NTT DOCOMO corporate website (http://www.docomo. biz/html/service/officeed/) (in Japanese only). Setting voice mail service "TEL function" "Voice mail service" Select an item Setting call waiting "TEL function"...

  • Page 50: Emergency Call

    For a country code, international call access code, universal number international prefix, available countries and overseas operators, refer to "Mobile Phone User's Guide [International Services]" or DOCOMO "International Services website". Overseas usage fees (call charge, packet communications charge) differ from those in Japan.
  • Page 51 Available services overseas Main communication services GSM/GPRS MyFACE Voice call Videophone call i-mode i-mode mail i-Channel *4 *5 i-concier i-Widget Packet communications via a PC Obtaining location information using GPS *1 : "Auto-upd set. roam" setting is required. Packet communications charges will apply when you automatically update MyFACE content that was registered at the time of purchase.
  • Page 52 Making a call to outside the country you stay in On the standby screen, (1 second or longer) to enter + s    s     s C ountry code A rea code (City code) The other party's   s   phone number (voice call) / (V.phone)
  • Page 53 Mail Only by subscribing to i-mode, Mail can be exchanged between i-mode users or anyone who has an Internet e-mail address. You can send up to 10 attachments (images, moving picture files, etc.) of up to 2 MB in addition to the message (The maximum number of the files varies depending on the file size).
  • Page 54 Sending Deco-mail/Decome-Anime Deco-mail Decome-Anime Deco-mail is a service that Decome-Anime is a service a l l ows yo u to d e co rate that allows you to compose i-mode mail by changing d e c o r a t i v e m a i l u s i n g the character color/size and animation templates with background color, waving...
  • Page 55 "Inbox" Select a folder Select an i-mode mail Received mail detail screen Received mail list screen Replying to i-mode mail On Received mail list screen/Received mail detail screen Compose message (Send) To quote the received message to reply, press ) for 1 second or longer. Checking new i-mode mail You can receive the i-mode mails and messages stored at the i-mode center by checking with the center.

  • Page 56: Select An Item

    This service allows you to exchange SMS between mobile phones, or with subscribers to overseas operators. For countries and overseas operators, refer to "Mobile Phone User's Guide [International Services]" or the DOCOMO "International Services website". Sending SMS "Compose new SMS"...

  • Page 57: Phonebook

    Phonebook Adding phonebook entries FOMA terminal has two types of phonebooks: FOMA terminal phonebook that various functions can be set to and UIM phonebook whose entries are available even in another terminal. Adding phone numbers, mail addresses, etc. An entry cannot be stored unless you fill in the "Name" field. "TEL function"...
  • Page 58 i-mode/Full Browser i-mode You can use online services such as i-mode site connection, accessing to Internet, i-mode mail, with i-mode by using display of i-mode compatible terminal. i-mode requires a subscription and is a fee based service. For details on i-mode, refer to "Mobile Phone User's Guide [i-mode] FOMA version". Information on i-mode menu sites and Internet websites is generally protected by copyright law.

  • Page 59: Displaying Web Pages Designed For Pc

    Browsing i-mode site " " flashes while communicating, and " " flashes while receiving i-mode services (during i-mode). Scroll down to the bottom of the Communicating screen Connected screen iMenu screen to select "English" Displaying web pages designed for PC "i-mode/web"...

  • Page 60: Saving Site Contents

    Storing frequently accessed sites Website displayed using i-mode or Full Browser (Submenu) "Bookmark" "Add bookmark" "OK" Select a folder "OK" To view bookmarked site "i-mode/web" "Bookmark" Select a folder Select a bookmark Saving site contents Website displayed using i-mode or Full Browser (Submenu) "Screen Memo"...
  • Page 61 The ticker on the standby screen shows latest information that is automatically delivered to your terminal. "Basic Channel": This channel is distributed by DOCOMO. Packet communications charges do not apply to automatically update basic channels. "Okonomi (Optional) Channel": This channel is distributed by information service providers (IP).

  • Page 62: Map/Gps

    Map/GPS Under no circumstances shall DOCOMO be held liable for any loss or damage, due to loss of opportunity such as positioning (communicating) result check, resulting from external causes such as failure, malfunction or battery death of the FOMA terminal or blackout.
  • Page 63 Set whether to regularly send automatically collected location information by AUTO-GPS function to DOCOMO. Automatically sending location information to DOCOMO enables you to use i-concier or other services that are linked to services provided by DOCOMO. To use services, you need to apply for them or set them.
  • Page 64 Camera Viewing and operating shooting screen Shooting in Communication style Photo (still image) shooting screen Movie (moving picture) shooting screen Remaining storage count/Memory info Save Scene Focus frame Zoom Submenu setting status Key operation guidance Face selection mode Self timer Light setting Display orientation My shot setting...
  • Page 65 Shooting in Touch style In Touch style, touch on Photo/Movie shooting screen to display a palette, on which you can set various shooting options with touch operation. Back/Set Function Touch a function name to display the setting palette of the function. Other menu View the setting palette of functions not displayed here.
  • Page 66 Viewing still images/moving pictures after shooting Still images are saved in "My picture", and moving pictures are saved in "i-motion/movie" under Data box. Still images/moving pictures can be set to the standby screen, etc. Viewing still images/moving pictures in Data box "Data box"...
  • Page 67 1Seg Using 1Seg 1Seg service is provided by broadcasting companies (broadcasters). Communications charges do not apply to receive video and voice data. For details on NHK receiving fees, contact NHK. * Packet communications charges apply to view data broadcast site and i-mode site. Information charges may apply for some sites (i-mode pay sites).

  • Page 68: Setting Channels

    Setting channels When you use 1Seg for the first time or move to another area, set the channels. "CAMERA/TV/MUSIC" "1Seg" "Channel setting" "Auto channel setting" "YES" "YES" Enter title To select an area and register a channel list "CAMERA/TV/MUSIC" "1Seg" "Channel setting"...
  • Page 69 Music Music&Video Channel Music&Video Channel is a service that automatically performs overnight downloads of programs of up to approximately two hours in length. Also, up to approximately one hour of high quality video programs can also be delivered. After just configuring it once, Music&Video Channel automatically updates content, so you can always carry the latest videos and audio programs with you.

  • Page 70: Playing Programs

    Setting programs Choose a program you want to enjoy, and the program data will be automatically downloaded overnight. You can set 2 programs at a time. "CAMERA/TV/MUSIC" "Music&Video Channel" "Program set." Follow the on-screen instructions to set a program You may need to register a site providing Music&Video Channel programs to My Menu before setting a program.
  • Page 71 Some programs/tracks have playback restrictions. " " or " "appears at the beginning of the title for the program/track with restrictions on the play count, period or time limit. The program/ track whose playback period is restricted cannot be played before or after the period. If the battery pack is removed from the FOMA terminal for more than approx.

  • Page 72: I- Α Ppli/I-Widget

    ppli/i-Widget α ppli are software applications that run on i-mode compatible terminals. You can automatically receive α updated stock prices, weather information, etc., and play games without being connected to the network, by downloading i- ppli from i-mode sites. The FOMA terminal also supports i- ppli online which allows α...

  • Page 73: I-Motion/Movie

    i-motion/Movie i-motion/Movie i-motion is sounds, moving pictures, etc. Download i-motion from i-motion-downloadable sites to the FOMA terminal. You can download and play various movies provided on websites such as portal sites or moving picture sites. * When downloading/streaming movies, the received file size may become very large. Note that packet communications charges may be high when large files such as streaming type with no file size restriction are received.
  • Page 74 Osaifu-Keitai service supporting the backup service. Please be aware that DOCOMO is not responsible for loss or alteration of the IC card data, any monetary losses incurred while using Osaifu-Keitai services under any circumstance such as malfunction or changing your model.
  • Page 75 For details on i-concier, refer to "Mobile Phone User's Guide [i-mode] FOMA version". Receiving information Icon When you receive information, " " appears at the top of the screen. Pop up On the standby screen Select a pop up message message Displaying i-concier " ® (Butler Sheep)" ©NTT DOCOMO "i-concier"...

  • Page 76: Convenient Tools

    Convenient Tools Using Shabette-Kensaku Say the keyword in Japanese to use i-mode search. "Tool" "next" "Shabette-Kensaku" When using for the first time, select "Use" on the usage guide screen. Within 10 seconds, say the keyword into the mouthpiece/microphone when the vibrator vibrates and "Speak keyword in Japanese" appears (Fix) The vibrator vibrates and the i-mode search results screen is displayed.

  • Page 77: Using Alarm

    JAN code : When you scan the JAN code shown to the right with the FOMA terminal, "4942857113068" is displayed. QR code : When you scan the QR code shown to the right with the FOMA terminal, " (NTT DOCOMO, INC.)" is displayed.

  • Page 78: Using Bluetooth Function

    Using Bluetooth function Registering a Bluetooth device to FOMA terminal If the Bluetooth device you want to use has not been registered, register it. Up to 10 Bluetooth devices can be registered. Place the Bluetooth device to be registered on standby beforehand. "Tool"...

  • Page 79: Data Management

    This FOMA terminal supports commercially available microSD cards of up to 2 GB and microSDHC cards of up to 32 GB (as of October, 2011). Make sure to format microSD card on N-02D. You may not be able to use microSD card formatted on another terminal or PC.
  • Page 80 Formatting microSD card Note that all data in the microSD card will be deleted when you format it. "Tool" "microSD" "Refer microSD data" (Submenu) "microSD format" Enter your security code "YES" Viewing data in microSD card <Example: To display phonebook> "Tool"...
  • Page 81 "DCIM" folder and other files are moved to the "PRIVATE/DOCOMO/STILL" folder. *2: Extension changes to "MID" after being imported. *3: Schedule is also included in memos created with N-02D, in VCS format. Sending/receiving data by infrared communication Exchange data such as phonebook entries and received mail Infrared data port with other devices equipped with the infrared communication.

  • Page 82: Connecting To A Pc

    To transfer data, you need to install the "FOMA communication setting file" (driver). For details, refer to the "Manual for PC Connection". "FOMA communication setting file" (driver) and "Manual for PC Connection" can be downloaded from NTT DOCOMO website. http://www.nttdocomo.co.jp/english/support/ DOCOMO Connection Manager "DOCOMO Connection Manager"...
  • Page 83 ( p.86) If you are still unable to identify the problem after checking the points, please contact "Repairs" on the last page of this manual (in Japanese only) or a repair counter specified by DOCOMO. The power will not turn on Is the battery pack properly attached? p.21...
  • Page 84 Battery life is very short Is the FOMA terminal left outside the service area for a long time? In a place outside the service area, the terminal searches the radio waves for communication and the battery is consumed more quickly. The available operating time of the battery pack depends on the conditions of usage and degraded degree of battery pack.
  • Page 85 Cannot make a call by pressing the dial keys Is Original Lock for "Keypad dial" under "Dial/sending mail" set? p.41 Is Auto-key lock set? p.41 Is Restrict dialing set? Is Dial lock set? p.41 Is Self mode set? Calls cannot be made or received (" "...
  • Page 86 If, after contacting DOCOMO, you are informed that your FOMA terminal needs repairs Bring it to a repair counter specified by DOCOMO. The repair counter is only open during business hours. Depending on the malfunction, repairs may take some time.

  • Page 87: Error Info Send Set

    - Put stickers, etc. on the LCD or keys - Decorate the FOMA terminal using adhesives, etc. - Replace the external parts, etc. with non-DOCOMO components If malfunction or damage occurs as a result of modification, charges will apply even if the FOMA terminal is still under warranty.

  • Page 88: Updating Software

    When software is updated, the unique information (model, serial number, etc.) of your FOMA terminal is automatically transmitted to the server at DOCOMO. We do not use the transmitted information for any purposes other than Software Update.

  • Page 89: Scanning Function

    Running software update by selecting the icon Select the icon (Update icon) on the standby screen to update software. Select the Update icon "Yes" Enter your security code Your FOMA terminal is checked if it needs an update. The check result appears When "Update is needed"...
  • Page 90 Scanning results display Scanned problems display A list of up to 5 problems detected by the Scanning function appears, starting with the highest-level problem. If 6 or more problems are detected, the names of the 6th and subsequent problems are omitted. Scanning results display Warning level 0 Warning level 1...

  • Page 91: Options And Related Devices

    FOMA Dry Battery Adapter 01 FOMA eco Solar Panel 01 *1 To connect to N-02D, the Earphone Plug Adapter P001 or Earphone Plug Adapter 01 for External connector terminal is required. *2 To connect to N-02D, the Earphone Plug Adapter 01 for External connector terminal is required.
  • Page 92 Appendix Menu list settings are reset to default by "Reset settings". Some functions that cannot be reset to default settings (or default states) may be included in settings. Main item Sub item Branch item Main item Sub item Branch item Mail Inbox mode/web...
  • Page 93 Phrases/Store word Recording result Store word TVlink Download dictionary Channel list Voice quick start Channel setting Shabette-Kensaku User setting Contact DOCOMO MUSIC Player Phonebook Search phonebook TEL function Music&Video Channel Add to phonebook My picture Data box UIM operation MUSIC Phonebook set./...
  • Page 94 Main item Sub item Branch item Main item Sub item Branch item Headset function set. Setting Screen/Display Viewer settings TEL function Dial/Receive setting Call rejection set. Icons Icons setting Missed call notice Visual preference Privacy angle Videophone setting Select image Display on charge Auto redial as voice Image display mode...
  • Page 95 Main item Sub item Branch item Main item Sub item Branch item Setting Battery Battery level Map/Overseas GPS set./ Illum./Tone history settings USB mode External connection 3G/GSM setting Bluetooth Overseas NW search Headset microphone Network search setting Femtocell Other setting Side key guard PLMN setting Set assigned...

  • Page 96: Main Specifications

    Main specifications Phone Product name N-02D Size (When folded) Height approx. 112 mm x Width approx. 51 mm x Thickness approx. 12.9 mm (Thickest : Approx. 18.4 mm) Weight Approx. 131 g (Battery pack attached) Continuous standby time [FOMA/3G] Stationary ("AUTO"...
  • Page 97 *1 : Switch networks in "3G/GSM setting". *5 : Varies depending on the broadcaster and *2 : Size = QVGA (320 x 240), Quality = Normal (File program. size = 25 KB) *6 : File format = AAC *3 : Varies depending on the size. *7 : Background playback supported *4 : Recording time for 1 item under the following conditions: *8 : For Chaku-Uta®, up to approx.
  • Page 98 Specific absorption rate (SAR) of mobile phone Specific Absorption Rate (SAR) of Mobile Phones This model N-02D mobile phone complies with Japanese technical regulations and international guidelines regarding exposure to radio waves. This mobile phone was designed in observance of Japanese technical regulations regarding...
  • Page 99 Radio Frequency (RF) Signals THIS MODEL PHONE MEETS THE U.S. GOVERNMENT'S REQUIREMENTS FOR EXPOSURE TO RADIO WAVES. Your wireless phone contains a radio transmitter and receiver. Your phone is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the U.S.

  • Page 100: Export Administration Regulations

    Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Declaration of Conformity The product N-02D is declared to conform with the essential requirements of European Union Directive 1999/5/EC Radio and Telecommunications Terminal Equipment Directive 3.1 (a), 3.1 (b) and 3.2.

  • Page 101: Intellectual Property Right

    Morpho, Inc. in Japan and other countries. "i-area", "WORLD WING", "OFFICEED", "2in1", IrSimple™, IrSimpleShot™ and IrSS™ "docomo STYLE series" and "iC" logo are trademarks Trademarks are owned by the Infrared Data or registered trademarks of NTT DOCOMO. Association® and used with permission therefrom.
  • Page 102 LICENSED BY MPEG LA TO PROVIDE MPEG-4 VIDEO. NO This product contains NetFront Browser, NetFront LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY Document Viewer and NetFront Sync Client of OTHER USE. ADDITIONAL INFORMATION INCLUDING ACCESS CO., LTD. THAT RELATING TO PROMOTIONAL, INTERNAL AND ACCESS, the ACCESS logo, and NetFront are COMMERCIAL USES AND LICENSING MAY BE OBTAINED registered trademarks or trademarks of ACCESS...
  • Page 103 Bluetooth SIG, INC. and any use of such provided that the following conditions are met: marks by NTT DOCOMO, INC. is under license. - Redistributions of source code must retain the Other trademarks and trade names are those of above copyright notice, this list of conditions their respective owners.

  • Page 104: Index

    Desktop holder ............22 Area Mail ..............53 Desktop icon ............26 Auto receive mail ............ 52 Dial lock ..............41 Auto-key lock ............41 docomo Palette UI........... 29 Download Chaku-Uta-Full® ............68 Backlight ..............36 i-motion .................71 Bar code reader ............75 ppli................70...
  • Page 105 IC card lock ............... 41 Lock function ............41 iC transmission ............80 Lock/Security i-Channel ..............59 Auto-key lock ...............41 Icon description ............25 Dial lock .................41 i-concier ..............73 IC card lock ..............41 Illumination .............. 37 Omakase Lock..............41 i-mode ............... 56 Original Lock ..............41 Display i-mode site ............57 Touch panel lock ............42...
  • Page 106 Part names and functions .........4 Scanning function ........... 87 Pattern data update ..........87 Scanning results display ...........88 Phone Update pattern data ..........87 Make a call by entering the phone number ..44 Schedule ..............75 Make a call from phonebook ........44 Security code ............
  • Page 107 Volume ..............45 Warranty ..............84 Waterproof/dustproof function ......17 When you cannot answer a call Public mode (Drive mode)........46 Public mode (Power OFF) ........46 Record message ............46 WMA ................68 WORLD CALL ............45 WORLD WING ............48 Numerals, etc. 1Seg ................
  • Page 108 * Packet communications charges do not apply to use via i-mode. Charges will apply if using the service from overseas. * "docomo ID/password" are required to use this site from a PC. * Please contact "General Inquiries" on the last page of this manual if you forget or do not have "Network security code"...
  • Page 109 (Business hours : 9:00 a.m. to 8:00 p.m. (open all year round)) Please confirm the phone number before you dial. For Applications or Repairs and After-Sales Service, please contact the above-mentioned information center or the docomo shop etc. near you on the NTT DOCOMO website or the i-mode site.
  • Page 110 About Manual for PC Connection This manual describes necessary information for data communication using the FOMA terminal and how to install "FOMA communication setting file" and "DOCOMO Connection Manager". The procedures or screens may vary depending on your environment. The words which represent the FOMA terminal model name, such as driver names and modem names, are referred to as "...

  • Page 111: Data Communication

    It is not compatible with FOMA HIGH-SPEED Area communication. You can also access a corporate LAN connected to the FOMA network. Use an access point that supports FOMA packet communication, such as DOCOMO Internet connection service “mopera U”. For packet communication, connect the FOMA terminal to a PC using FOMA USB Cable with Charge Function 02 (optional), Bluetooth communication* or Wi-Fi connection, or to a PDA using a dedicated cable.
  • Page 112 64K data communication is charged according to the length of time the line is connected, regardless of the amount of data. Use an access point that supports FOMA 64K data communication, such as DOCOMO Internet connection service “mopera U”, or ISDN synchronized 64K access point.
  • Page 113 Internet. These fees must be paid directly to the Internet service provider in addition to service fees of FOMA service. Contact your Internet service provider for details. DOCOMO Internet connection service "mopera U" is available. "mopera U" is a pay service for which you need to apply.

  • Page 114: Before Using

    For the latest information on the operating environment, visit the DOCOMO website. NOTE d You can transmit data with the FOMA terminal connected to the DOCOMO PDA "sigmarion ". d This FOMA terminal is not compatible with Remote Wakeup function.

  • Page 115: Checking The Procedure

    64K data communication and data transfer (OBEX FOMA communication setting file embeds each driver into Windows. Using DOCOMO Connection Manager, you can easily set up packet communication and 64K data communication and create a dial-up connection. Flow chart for completing the data communication setup...
  • Page 116 <Not using "DOCOMO Connection "DOCOMO Connection Manager"> Manager"> Download "DOCOMO Connection Manager" from the DOCOMO website, and install it to PC a Enables you to use DOCOMO Connection Manager. "Installing DOCOMO Connection Manager" p.17 Set up Set up a mopera U a Set up communication not using "DOCOMO Connection...
  • Page 117 Setting the USB mode to "Communication mode" d Set the mode before connecting to PC. d Setting is not required when using Bluetooth connection or Wi-Fi connection. MENU key "Setting" "External connection" "USB mode" "Communication mode"...

  • Page 118: Installing The Foma Communication Setting File (Drivers)

    " (Close) or " " (Finish). Access the FOMA communication setting file (drivers) download page on DOCOMO website Access http://www.nttdocomo.co.jp/support/utilization/application/foma/com_set/driver/index.html (in Japanese only) Go to the driver download page for the in-use model Upon confirming the user agreement, click "...
  • Page 119 When this screen appears, click The title bar display differs depending on the in- use OS. Turn on the FOMA terminal, then connect the FOMA USB Cable with Charge Function 02 (optional) to your FOMA terminal For connecting the FOMA terminal and FOMA USB Cable with Charge Function 02, refer to the Instruction Manual for the FOMA terminal.

  • Page 120: Device Manager

    Checking the installed driver Check that the FOMA communication setting file (drivers) has been correctly installed. This section describes an example using Windows 7. Select " " " " (Control Panel) For Windows XP Select " " (Start) " " (Control Panel) Open "...
  • Page 121 Uninstalling the FOMA communication setting file (drivers) If necessary (when updating the drivers, etc.), uninstall the drivers as follows. The procedure for uninstalling from a Windows 7 or Windows Vista machine is described as an example. d Uninstallation is not available while connecting the FOMA terminal with PC. d When uninstalling FOMA communication setting file, be sure to log on as Administrator.

  • Page 122: Preparing Bluetooth Communication

    Preparing Bluetooth Communication Perform data communication by connecting a Bluetooth communication compatible PC to the FOMA terminal wirelessly. Register and connect the PC to the FOMA terminal To connect a PC to the FOMA terminal for the first time, register the PC to the FOMA terminal. MENU key "Tool"...
  • Page 123 Select " " (Device Manager) When the User Account Control screen appears, click " " (Yes). For Windows Vista Select " " (Device Manager) When the User Account Control screen appears, click " " (Continue). For Windows XP Click the " "...

  • Page 124: Connecting To A Wi-Fi-Compatible Pc

    Connecting to a Wi-Fi-compatible PC Packet communication is possible by setting the FOMA terminal as an access point and connecting the FOMA terminal and a Wi-Fi-compatible PC via Wi-Fi. d Set the FOMA terminal to Access point mode beforehand. Refer to the Instruction Manual for the FOMA terminal for how to set to Access point mode and details for Access point mode settings.

  • Page 125: Docomo Connection Manager

    DOCOMO Connection Manager DOCOMO Connection Manager is a useful software for performing the flat-rate data communications and the measured-rate data communications. "DOCOMO Connection Manager" enables simplification of mopera U subscription, or appropriate setting on PC depending on the subscription. The fare counter function is also available for checking an indication of the data traffic or usage amount.
  • Page 126 Log on as a user who uses DOCOMO Connection Manager When installing DOCOMO Connection Manager, be sure to log on as a user with Administrator privilege. If you attempt to install the software with another account, an error may occur.

  • Page 127: Installing Docomo Connection Manager

    Other connection software than DOCOMO Connection Manager d DOCOMO Connection Manager provides the same functions as the ones included in other connection software listed below, and this is all you need. Disable or uninstall the following software, if necessary.
  • Page 128 Click " " (Next) Confirm the precautions and click " " (Next) Upon confirming the user agreement, click " " (Agree) to agree to it, and click " " (Next) Select the installation location and click " " (Next) If you want to change the location, click " "...

  • Page 129: Starting Docomo Connection Manager

    " (DOCOMO Connection Manager) Specify the settings by following the setting wizard The setting wizard will automatically appear when you start DOCOMO Connection Manager for the first time. Follow the guidance and you can make preparations for Internet connection. For details, refer to "...

  • Page 130: Executing Set Data Communication

    Executing Set Data Communication Start DOCOMO Connection Manager "Starting DOCOMO Connection Manager" p.19 Click the tab of the desired connection method, and click " " (Connect) For details, refer to " " (DOCOMO Connection Manager operating manual). When connection is not available, check “Setting up Dial-up Network” (p.22) and “Setting up Dial-up”...
  • Page 131 When you do not perform data communication, be sure to disconnect by the following procedure: Click " " (Disconnect) on the DOCOMO Connection Manager screen Click " " NOTE d With Windows OS, software will be automatically updated if set to do so, and you may incur high packet communications charges without knowing you are doing so.

  • Page 132: Setting Up Dial-Up Network

    Setting up Dial-up Network This section describes how to set up a dial-up connection for packet communication / 64K data communication without using DOCOMO Connection Manager. The flow of operation is described below. d It is unnecessary to set up the dial-up network for 64K data communication. Go on to "Setting up Dial- up"...
  • Page 133 Click the " " (Modem) tab to confirm the COM port of the " " (Access point) column of the in- use FOMA terminal, and click "OK" When connecting wirelessly using Bluetooth communication, confirm the COM port number of the in-use Bluetooth linked standard modem or Bluetooth modem provided by a Bluetooth device maker in the "...
  • Page 134 d To check the COM port on Windows XP Open " " (Start) " " (Control Panel) Open " " (Telephone and modem options) from " " (Printers and other hardware) in Control Panel If the " " (Address information) screen is displayed, enter " "...
  • Page 135 Phonebook of mobile phone Data to be registered Phone number Memory number of Phonebook Other party's name How to register Register using PC Available (DOCOMO Connection Available (Dedicated software Manager, etc.) required) Register using Mobile phone Unavailable (Cannot even check) Available...
  • Page 136 Click " " (Start) " " (All programs) " " (Accessories) " " (Communication) " " (Hyper terminal) to start Hyper terminal Select the " " (Do not display this message again) checkbox and then click " " (Yes) Enter any name in the " "...
  • Page 137 Enter the access point (APN) and press Enter in the format of AT+CGDCONT=<cid>, "PDP_type", "APN" <cid> Enter any number between 5 and 10. Please be cautious because if cid has been already set, the setting will be overwritten. "PDP_type" Enter "PPP" or "IP". "APN"...
  • Page 138 " (File) menu NOTE d The Caller ID needs to be set to "Notify" to use DOCOMO's internet connection service mopera U or mopera. About 186 (Notify)/184 (Not notify) in Dial-up Network You can attach 186/184 to the access point number in the Dial-up network settings as well.

  • Page 139: Setting Up Dial-Up

    Setting up Dial-up d This section takes accessing mopera U by packet communication for example. d To connect using packet communication, enter " 3#" as the number of access point for mopera U or " 1#" for mopera. To connect using 64K data communication, enter " 8701"...
  • Page 140 Click (Network and Internet) (Show network status and task) (Connect to network) on Control Panel Right-click the icon created for the dial-up and click " " (Properties) Confirm the settings on the " " (General) tab If two or more modems are connected to the When connecting using the FOMA USB Cable with Charge Function 02, confirm that only the in-use FOMA terminal is checked in the "...
  • Page 141 Click the " " (Options) tab and click "PPP " (PPP settings) Clear all the boxes and click "OK" Click "OK" Setting up dial-up on Windows Vista Open " " " " (Access point) Click " " (Set up the connection or network) Select "...
  • Page 142 Click " " (Set up the connection) and then " (Close) Open " " " " (Access point) Right-click the icon created for the dial-up and click " " (Properties) Confirm the settings on the " " (General) tab If two or more modems are connected to the When connecting using the FOMA USB Cable with Charge Function 02, confirm that only the in-use FOMA terminal is checked in the "...
  • Page 143 Click the " " (Options) tab and click "PPP " (PPP settings) Clear all the boxes and click "OK" Click "OK" Setting up dial-up on Windows XP Open " " (Start) " " (All programs) " " (Accessories) " " (Communication) "...

  • Page 144: Network Connections

    Enter any name you want in the "ISP " (ISP Name) and click " " (Next) Enter the number of the access point in the " " (Telephone Number) column and click " " (Next) This screen is an example of accessing mopera U by packet communication.
  • Page 145 Select the icon created for the dial- up and open " " (Properties) in the " " (File) menu Confirm the settings on the " " (General) tab If two or more modems are connected to the When connecting using the FOMA USB Cable with Charge Function 02, confirm that only the in-use FOMA terminal is checked in the "...
  • Page 146 When the Step 14 screen reappears, click "OK" Running dial-up connection This section describes how to make a dial-up connection for packet communication by using the dial- up setting. <Example: Using the FOMA USB Cable with Charge Function 02 on Windows 7> Connect the FOMA terminal to the PC with the FOMA USB Cable with Charge Function 02 (optional) Open "...
  • Page 147 <Completion of the connection> When the connection is complete and a screen indicating the completion of the connection appears, click " " (Close). (Depending on the OS, a message appears from the indicator of the taskbar located on the bottom-right of the desktop for a few seconds.) You can start browser software to view sites and websites or to use e-mail.
  • Page 148 AT Command List AT commands available on FOMA terminal d The following abbreviations are used in the AT command list; [&F] : Command of which setting is initialized by AT&F command. [&W] : Command of which setting is saved by AT&W command. The setting can be retrieved by ATZ command.

  • Page 149: At Command List

    AT command Outline Parameter/description Command execution example AT&W Stores the current settings. Only = 0 can be specified (can be omitted). AT&W0 AT&W AT&W? ERROR AT&W ? ERROR DANTE Displays the FOMA terminal DANTE FOMA terminal signal reception level is displayed as signal reception level.
  • Page 150 AT command Outline Parameter/description Command execution example AT+CBC Displays the battery status Result: +CBC:<bcs>,<bcl> AT+CBC of the FOMA terminal. bcs: +CBC:0,70 0 : FOMA terminal is powered by the battery. 1 : FOMA terminal is not powered by the battery. AT+CBC? 2 : FOMA terminal is not connected to the battery.
  • Page 151 AT command Outline Parameter/description Command execution example AT+CLIP= Displays the other party's = 0 : Not display the result (initial value) AT+CLIP=0 Caller ID on a PC when a = 1 : Display the result 64K data communication call is received. AT+CLIP? AT+CLIP? +CLIP:0,1...
  • Page 152 AT command Outline Parameter/description Command execution example AT+COPS Selects the network Format : AT+COPS=<mode>,2,<oper> AT+COPS=0 operator to connect. mode=0 : automatic (searches the network AT+COPS? and switches the network operator +COPS:0 automatically) mode=1 : manual (connects to the network AT+COPS=? operator specified in <oper>) +COPS:(2,,,"44F001"), mode=2 : Disconnects the connection to the...
  • Page 153 AT command Outline Parameter/description Command execution example AT+CPIN Enters the PIN code in the Format: AT+CPIN="<pin>","<newpin>" (The status in which FOMA terminal. +CPIN: READY is This command is to enter the PIN1, answered when PIN2, or PUK code - depending on +CPIN? is entered) the state of the result code returned AT+CPIN="1234"...
  • Page 154 AT command Outline Parameter/description Command execution example AT+CREG= Specifies whether the result = 0 : Not informed (initial value). AT+CREG=1 screen is present regarding = 1 : Informed. the inside/outside the (Set to informed) Informed when switching between service area information "Inside the service area"...
  • Page 155 = 0 : Disconnect the line (can be omitted). (During packet for the FOMA terminal. communication) NO CARRIER Displays the ID code. = 0 : Displays "NTT DoCoMo". ATI0 NTT DoCoMo = 1 : Displays the product name (same with +GMM). ATI1...
  • Page 156 AT command Outline Parameter/description Command execution example ATS0= Specifies how many times = 0 : No automatic answer (initial value). ATS0=0 the FOMA terminal rings = 1- 255: A call is automatically answered before it automatically ATS0? after the specified number of receives a call.
  • Page 157 AT command Outline Parameter/description Command execution example ATS104= Sets the calling sub address = 0 : # ATS104=0 character. = 1 : % (initial value) = 2 : & ATS104? ATS104=? [&F] ERROR Specifies whether the result = 0 : Returns the result code in numeral ATV1 code is returned in numerals value.
  • Page 158 d Supplementary explanation of AT command Commands which do not function The following commands do not generate errors but will not function as a command: ATT (Tone setting) ATP (Pulse setting) Command name: +CGDCONT=[parameter] Outline Sets the access point name (APN) for packet origination. Though this command is a setting command, it will not be recorded in non-volatile memory written by [&W], nor reset by [&F] or [Z].
  • Page 159 Command execution example Only the following 4 patterns can be set. (1) is set as an initial value to each cid. Command for permitting all speeds of both uplink and downlink (when cid is 5) AT+CGEQMIN=5 Command for permitting only the speed of uplink 5,760kbps and downlink 7,232kbps (when cid is 6) AT+CGEQMIN=6,,5760,7232 Command for permitting uplink 5,760kbps and all speeds of downlink (when cid is 7) AT+CGEQMIN=7,,5760...

  • Page 160: Result Codes

    Result codes Result codes related with data communication Number Character indication Description indication Successfully executed. CONNECT Connected. RING Incoming call. NO CARRIER Line disconnected. ERROR Command not acceptable. NO DIALTONE Unable to detect dialing tone. BUSY Busy tone detected. NO ANSWER Time out in connection completing.
  • Page 161 Result code display example When ATX0 is set Regardless of the AT¥V command (p.45) setting, only CONNECT appears when the connection is completed. Character indication example: ATD CONNECT Number indication example: When ATX1 is set ATX1, AT¥V0 are set (default) Displayed in CONNECT <rate between the FOMA terminal and the PC>...
  • Page 162 Kuten Code List...

  • Page 163: Kuten Code List

    Kuten Code List <Guide to the kuten code table> First enter “digits 1-3 of the kuten code” then “digit 4”. d Some kuten codes in the table here may look different from what actually appear on screens. First to third First to third First to third Fourth digit of Kuten codes...
  • Page 164 First to third First to third First to third Fourth digit of Kuten codes Fourth digit of Kuten codes Fourth digit of Kuten codes digits of digits of digits of Kuten codes Kuten codes Kuten codes...
  • Page 165 First to third First to third First to third Fourth digit of Kuten codes Fourth digit of Kuten codes Fourth digit of Kuten codes digits of digits of digits of Kuten codes Kuten codes Kuten codes...
  • Page 166 First to third First to third First to third Fourth digit of Kuten codes Fourth digit of Kuten codes Fourth digit of Kuten codes digits of digits of digits of Kuten codes Kuten codes Kuten codes...

Table of Contents
