FRONT PANEL INDICATORS

1. POWER ON INDICATOR: The power LED will glow
blue when power is applied.
2. CH A & CH B: Illuminate red when the audio for the
corresponding microphone is received.

TOP PANEL CONTROLS

1. CHANNEL A VOLUME: Controls the volume level of the
microphone set to channel A.
2. CHANNEL B VOLUME: Controls the volume level of the
microphone set to channel B.
2 1 2
CH A PWR CH B
1 2
CH B
CH A MICROPHONE
MIN MAX MIN MAX
7
