Lightspeed Redcat User Manual page 18

6. OUTPUT TO ASSISTIVE LISTENING
DEVICE (ALD)
1. Turn the ALD (Assistive Listening
Device) volume control
on the Redcat side panel
counterclockwise all way the down.
2. Determine the size and type of
audio input jack on the device as
many manufacturers' products
differ in connector size and shape.
The Lightspeed 370 Transmitter
requires a 3.5mm to 3.5mm
patch cable (part# MSC3535, not
included).
3. Connect a patch cable from the
ALD's microphone jack or AUX
input to the 3.5mm audio jack
labeled "ALD OUT" on the side
18
of the Redcat.
4. With the Redcat and ALD turned
on, speak into the Redmike and
slowly adjust the ALD volume
control until the appropriate
audio level is attained in the ALD's
receiver headphones.
5. It may be necessary to adjust
the volume on the Personal FM
receiver to achieve appropriate
volume level.
