CRADLE CHARGER CONTROLS AND
CONNECTIONS
1
1. CHARGE INDICATORS: The light
glows red while the Redmike is
charging. When fully charged, the
light will glow green. A blinking
red light indicates that no battery
is sensed, (Redmike Yellow
Protective Tab may not have been
completely removed—see page
10, item 4.) A blinking green LED
means a non- Lightspeed battery
has been installed (possibly an
alkaline battery).
10
2
2. DC POWER PORT: Connect the
5V/1.0A DC power cord here.
3. OPTIONAL CHARGING PORT:
Plug the charging cord for
the optional Redmike Share
microphone here.
3
