1.2 Typical System Installation

The Voice-over-IP (VoIP) Intercom is a Power-over-Ethernet (PoE 802.3af) and Voice-over-IP (VoIP)
two-way communications device that easily connects into existing local area networks (LANs) with a
single cable connection. The intercom is compatible with most SIP-based IP PBX servers that
comply with SIP RFC 3261.
Figure 1-2
phone system.
Door Strike
Operations Guide
illustrates how the VoIP Indoor Intercom with Keypad can be installed as part of a VoIP
Figure 1-2. Typical Installation—Door Entry/Access Control
Generic PoE Switch
1
VoIP Intercom VoIP Intercom
Warning
Electrical Hazard:
GENERAL ALERT
Warning
Electrical Hazard:
according to all local electrical and building codes.
GENERAL ALERT
Warning
Electrical Hazard:
the floor/wall in accordance with the installation instructions.
GENERAL ALERT
Warning
The PoE connector is intended for intra-building connections only and does not
route to the outside plant.
GENERAL ALERT
2 3 4 5 6
The VoIP Intercom enclosure is not rated for any AC voltages.
This product should be installed by a licensed electrician
To prevent injury, this apparatus must be securely attached to
930915D
Typical System Installation
IP Phone
IP PBX Server
