2. On the Sensor Configuration page, enter values for the parameters indicated in
Web Page Item
Door Sensor Settings
Door Sensor Normally Closed
Door Open Timeout (in seconds)
Flash Button LED
Activate Relay
Play Audio Locally
Make call to extension
Play recorded audio
Dial Out Extension
Dial Out ID
Repeat Local Audio
Intrusion Sensor Settings
Flash Button LED
Activate Relay
Play Audio Locally
Make call to extension
Play recorded audio
Dial Out Extension
Dial Out ID
Repeat Local Audio
Note
Operations Guide
Table 2-14. Sensor Configuration Parameters
You must click on the Save button and then the Reboot button for the changes to take
effect.
930915D
Installing the VoIP Indoor Intercom with Keypad
Description
Select the inactive state of the door sensors.
Select the number of seconds that you want to pass before the door
sensor is activated.
Check this box to flash the LED until the sensor is deactivated
(roughly 10 times/second).
Check this box to activate the relay until the sensor is deactivated.
Check this box to loop an audio file out of the Intercom speaker
until the sensor is deactivated.
Check this box to call a preset extension (once).
Check this box to play a pre-recorded audio file (once).
Enter the desired dial-out extension number.
Type the desired Extension ID (64 character limit).
Type how many times that you want an audio file to repeat out of
the device's speaker after the sensor is activated. (Type 0 to make
an audio file repeat indefinitely).
Use this button to test the door sensor.
Check this box to flash the LED until the sensor is deactivated
(roughly 10 times/second).
Check this box to activate the relay until the sensor is deactivated.
Check this box to loop an audio file out of the Intercom speaker
until the sensor is deactivated.
Check this box to call a preset extension (once).
Check this box to play a pre-recorded audio file (once).
Enter the desired dial-out extension number.
Type the desired Extension ID (64 character limit).
Type how many times that you want an audio file to repeat out of
the device's speaker after the sensor is activated. (Type 0 to make
an audio file repeat indefinitely).
Use this button to test the Intrusion sensor.
Click the Save button to save your configuration settings.
Note: You need to reboot for changes to take effect.
Click on the Reboot button to reboot the system.
Intercom Setup
Table 2-14.
