Mount the Intercom
Figure A-33
shows a wall mounting option.
Figure A-33. Wall Mounting Option
121001A
Screw Accessory Kit
Slot
Closed
Wall Cutout
Faceplate
Assembly
Network Cable
to J1
Slot
Open
Drill Holes for Anchors
Nut
Backplate
Network Cable &
Ground Wire are
(Not Provided)
Ground Lug
Mounting Screws
Operations Guide
930915D
