Britax UNITY Instructions For Installation And Use Manual page 52

TRAVEL SYSTEM -
BRITAX STROLLER CLICK & GO™ADAPTOR
D. Then push the Press Pin in the bottom hole
and push into place.
E. Now replace the trim pull elastic underneath
the adaptor and hook. Place elastic in groove
shown below.
loop
HOW TO REMOVE THE BRITAX STROLLER ADAPTOR
If you need to remove the Britax Stroller Click & Go™ Adaptor ensure cover is moved
aside and handle is in "rocking position"
and then pull out. Pull out the locking pin and gently remove the adaptor away from
carry handle. Store for future use with these instructions.
The Stroller instruction book will also provide full instructions for use on a Stroller.
* Refer to page 13 for handle position
52
Hook elastic
behind the
adaptor and
place in groove
hook
. First unscrew the Press Pin half way
2
Push in Press Pin
D
