ADJUSTING THE
SHOULDER HARNESS
A. At the rear of the Infant Carrier, remove one of
the harness shoulder straps from metal Strap
Connector by slipping strap through open
slot. The Metal Strap Connector is shown in
diagram right.
B. Pull the shoulder strap through slot.
C. Insert the shoulder strap through the Infant
Carrier slot which will position the shoulder
strap level with or above the baby's shoulder
(see page 17). Ensure that the shoulder strap
passes through matching slots in the cover
and seat shell.
If a Padded Insert is used then that will need
to be re-positioned and the strap re-inserted
when changing the slot position.
HOW TO SET-UP
Metal Strap Connector
