HOW TO SET-UP

CROTCH STRAP

The Infant Carrier is fitted with two crotch strap positions. Correct location of crotch
strap will securely position the baby correctly in Infant Carrier and will prevent baby
from slipping further into Infant Carrier.
As baby grows the crotch strap must be moved to
the outer slot.
ADJUSTMENT OF CROTCH STRAP
A. Remove the Infant Carrier from car as instructed
on page 32.
B. Lift Infant Carrier cover to reveal crotch strap slot.
C. From the top side of Infant Carrier turn the crotch
3-bar slide and push through each slot as shown
right until the Crotch strap assembly is free from
the Infant Carrier.
D. Insert Crotch strap through restraint slot which
will position Crotch strap level with the baby's
crotch and feed back through other slot as shown
right.
IMPORTANT :
When replacing cover, ensure none of the
harness straps are twisted and that all straps
are secure by pulling each harness strap.
18
SMALLER BABY
Crotch
buckle
Fabric
Cover
Crotch
3-bar Slide
LARGER BABY
Crotch buckle
Infant Carrier Body
Infant
Carrier
Body
Fabric
Cover
Crotch
3-bar
Slide
