TO FIT CANOPY
A. With the viewing window flap on the
outside, grasp the Canopy ensuring the
two plastic frame sections at both sides
are aligned.
B. Push the two plastic frame sections at
both sides onto the Infant Carrier at the
inside of the handle pivot point.
C. Refit the elastic Canopy strap to the
dedicated elastic trim strap on each side of
the Infant Carrier.
NOTE: Elastic Canopy loops must always be
fitted when Canopy is in use.
D. The Canopy can be rotated to cover the
baby or opened by rotating to the desired
position.
TO REMOVE CANOPY
A. Ensure Canopy is in the collapsed
position. Unclip the elastic Canopy straps
which are secured by plastic hooks under
each handle attachment point.
B. Grasp the Canopy and pull it away from
the Infant Carrier ensuring the straps are
clear of catching any objects.
