IMPORTANT:
KEEP THIS BOOKLET IN THE PLACE PROVIDED ON THE CHILD RESTRAINT
CONVERTIBLE CAR SEAT
Instructions for Installation & Use
REARWARD
FACING
Birth to 2-3
years (approx)
Instructions for Installation & Use
ISOFIX COMPATIBLE
Birth to 4 years (approx)
Series No. 7200/A/2013/i
FORWARD
FACING
12 months to 4
years (approx)
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the safe-n-sound and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Britax safe-n-sound

Summary of Contents for Britax safe-n-sound

  • Page 1 CONVERTIBLE CAR SEAT ISOFIX COMPATIBLE Birth to 4 years (approx) Instructions for Installation & Use Series No. 7200/A/2013/i REARWARD FORWARD FACING FACING Birth to 2-3 12 months to 4 years (approx) years (approx) IMPORTANT: KEEP THIS BOOKLET IN THE PLACE PROVIDED ON THE CHILD RESTRAINT Instructions for Installation &...
  • Page 2 QUICK GUIDE FOR SEATBELT INSTALLATION REARWARD FACING SEE PAGE 32 - 34 & 38 FOR FURTHER INFORMATION Instructions for Installation & Use...
  • Page 3 QUICK GUIDE FOR SEATBELT INSTALLATION REARWARD FACING SEE PAGE 32 - 34 & 38 FOR FURTHER INFORMATION Instructions for Installation & Use...
  • Page 4 QUICK GUIDE FOR ISOFIX COMPATIBLE INSTALLATION REARWARD FACING SEE PAGE 35 - 37 & 38 FOR FURTHER INFORMATION Instructions for Installation & Use...
  • Page 5 QUICK GUIDE FOR ISOFIX COMPATIBLE INSTALLATION REARWARD FACING SEE PAGE 35 - 37 & 38 FOR FURTHER INFORMATION Instructions for Installation & Use...
  • Page 6 QUICK GUIDE FOR SEATBELT INSTALLATION FORWARD FACING SEE PAGE 63 & 66 FOR FURTHER INFORMATION Instructions for Installation & Use...
  • Page 7 QUICK GUIDE FOR SEATBELT INSTALLATION FORWARD FACING SEE PAGE 63 & 66 FOR FURTHER INFORMATION Instructions for Installation & Use...
  • Page 8 QUICK GUIDE FOR ISOFIX COMPATIBLE INSTALLATION FORWARD FACING SEE PAGE 64 - 65 & 66 FOR FURTHER INFORMATION Instructions for Installation & Use...
  • Page 9 QUICK GUIDE FOR ISOFIX COMPATIBLE INSTALLATION FORWARD FACING SEE PAGE 64 - 65 & 66 FOR FURTHER INFORMATION Instructions for Installation & Use...
  • Page 10 INTRODUCTION To be used only in a rearward-facing position until the infant's shoulders either reach the lower shoulder height marker (approximately 12 months of age) or reach the middle height marker (approximately 2 to 3 years of age). Then to be used in a forward-facing position until the child's shoulders reach the upper shoulder height marker (approximately 4 years of age).
  • Page 11 INTRODUCTION Magagamit lamang sa isang nakaharap sa likod na posisyon hanggang sa maabot ng balikat ng sanggol ang alinman sa ibabang marka ng taas ng balikat (humigit-kumulang 12 na buwang edad) o maabot ang panggitnang marka ng taas (humigit-kumulang 2-3 taong edad). Pagkatapos ay magagamit sa nakaharap sa unahan na posisyon hanggang sa maabot ng mga balikat ng bata ang itaas na marka ng taas sa balikat (humigit-kumulang 4 na taong edad).
  • Page 12 INTRODUCTION Να χρησιμοποιείται μόνο σε θέση στραμμένο προς τα πίσω μέχρι οι ώμοι του βρέφους είτε να φτάνουν στον κάτω δείκτη ύψους ώμου (περίπου 12 μηνών) είτε να φτάνουν στον μεσαίο δείκτη ύψους (περίπου 2 με 3 ετών). Κατόπιν να χρησιμοποιούνται σε θέση που...
  • Page 13 INTRODUCTION के व ल पीछे की तरफ मु ँ ह किये हु य े स् थ िति मे ं तब तक प् र योग करे ं जबतक या तो शिशु का कन् ध ा कन् ध े के निचले भाग के चिन् ह तक न पहु...
  • Page 14 The child should not sit in this restraint in the forward facing mode until their neck muscles are able to support their head. Britax recommends that you keep your child in a rearward facing restraint for as long as possible (or until the appropriate shoulder height marker is reached between 12 months and 2yrs approx).
  • Page 15 INTRODUCTION WHAT ARE ISOFIX LOW ANCHORAGES IN A VEHICLE? ISOFIX low anchorages are fixed, standardised anchoring points for securely installing an ISOFIX compatible child restraint in a vehicle fitted with ISOFIX low anchorages. They are an alternative method of installing the child restraint without using the car's seatbelt.

  • Page 16: Table Of Contents

    INDEX PAGE WARNINGS SHOULDER HEIGHT MARKERS A GROWING CHILD SHOULDER HEIGHT MARKERS SHOULDER HEIGHT MARKERS THE NEXT STEP REARWARD FACING FEATURES: REARWARD-FACING SUITABLE FOR USE INSTALLATION METHOD HOW TO INSTALL PREPARATION HOW TO INSTALL USING SEATBELT HOW TO INSTALL USING ISOFLEX CONNECTORS HOW TO INSTALL TOP TETHER HOW TO USE HOW TO REMOVE...

  • Page 17: Table Of Contents

    INDEX PAGE FORWARD FACING FEATURES: FORWARD-FACING SUITABLE FOR USE HOW TO INSTALL PREPARATION HOW TO INSTALL USING SEATBELT HOW TO INSTALL USING ISOFLEX CONNECTORS HOW TO INSTALL TOP TETHER HOW TO USE HOW TO REMOVE AIRCRAFT USE HOW TO INSTALL IN AN AIRCRAFT CARE &...
  • Page 18 • Fit the restraint firmly to the car seat. • Fit the harness firmly to the child. • A loose restraint or harness is dangerous. • Supervision of children is needed because they may be able to undo the buckles and adjusters. •...

  • Page 19: Warnings

    • Regularly check the restraint components, straps and other fitments for correct function and condition. If faulty, cease using and seek repair by Britax. • IF AN AIRBAG IS FITTED IN THE SEATING POSITION WHERE THE CHILD RESTRAINT IS TO BE FITTED, FOLLOW THE VEHICLE MANUFACTURERS WARNINGS AND INSTRUCTIONS.

  • Page 20: Shoulder Height Markers A Growing Child

    USE IN REAR FACING MODE BELOW EITHER OF THESE MARKERS Britax recommends that you keep your child in a rearward facing restraint for as long as possible until the middle shoulder height marker is reached. Instructions for Installation & Use...

  • Page 21: Shoulder Height Markers

    SHOULDER HEIGHT MARKERS A GROWING CHILD Rearward Facing Older Child (Rearward Facing) Newborn (Rearward Facing) Shoulder Shoulder Height Height Marker A Marker B Turn to forward-facing when the child's shoulders are between the lower marker A and middle marker B shoulder height markers. Forward Facing Child Use (Forward Facing) Discontinue Use (Forward Facing)
  • Page 22 At least 12 months of age. Britax recommends to maintain rearward facing while the infant can be accommodated comfortably or until the shoulders reach marker B. Marker B: MIDDLE SHOULDER HEIGHT MARKER...

  • Page 23: Shoulder Height Markers

    (eg: Safe-n-sound Maxi Rider Easy Adjust). • Or a dedicated booster seat with vehicle lap-sash seatbelt or seatbelt and compatible child harness until 6 to 8 years of age (eg: Safe-n-Sound Hi-Liner) or until 8 to 10 years of age (eg. Safe-n-Sound Encore 10).

  • Page 24: Rearward Facing

    FEATURES: REARWARD-FACING Shoulder height markers are exposed as the headrest is raised. 1. AHR Easy Adjust Headrest lever 2. AHR Easy Adjust Headrest (with SICT™) 3. Padded cover for comfort (may vary in style) 4. Harness Tongue holders Harness Tongues 5.

  • Page 25: Features: Rearward-Facing

    FEATURES: REARWARD-FACING Front of Vehicle RECLINE MECHANISM 13. Vehicle's Upper Anchorage fitting 14. Top Tether Attachment Clip 15. Vehicle seatbelt 16. Release Latch (rearward facing mode) 17. Recline Latch (recline mode) REARWARD FACING BELT PATH 18. Blue label shows 19. Rearward-facing Lock-off 20.
  • Page 26 FEATURES: REARWARD-FACING Shoulder height markers are exposed as the headrest is raised. 1. AHR Easy Adjust Headrest lever 2. AHR Easy Adjust Headrest 3. Side Impact Cushion Technology™ (SICT™) 4. Shoulder Pads (if fitted) 5. Harness Tongue holders Harness Tongues 6.
  • Page 27 FEATURES: REARWARD-FACING Front of Vehicle RECLINE MECHANISM 14. Car's Upper Anchorage fitting 15. Attachment Clip 16. Vehicle seatbelt 17. Release Latch (rearward facing mode) 18. Recline Latch (recline mode) REARWARD FACING BELT PATH 19. Blue label shows 20. Rearward-facing Lock-off 21.
  • Page 28 ISOFLEX FEATURES: REARWARD-FACING ISOFIX COMPATIBLE 30 31 27. ISOFLEX Strap Adjuster Button 28. ISOFLEX Strap 29. ISOFLEX Strap Adjuster 30. ISOFLEX Connector Release Button ISOFLEX Connectors are 31. ISOFLEX Connector located under the storage cover 32. Vehicle ISOFIX lower anchorage 33.

  • Page 29: Suitable For Use

    SUITABLE FOR USE IS THERE ENOUGH ROOM To ensure that the space is sufficient, the 380mm purchaser should check the measurements between the vehicle’s rear and front seats in which the child restraint is intended to be used. 600mm DO NOT USE RESTRAINT IN REARWARD FACING MODE WITHOUT THE STABILISING BAR FULLY EXTENDED.

  • Page 30: Installation Method

    INSTALLATION METHOD Select a seating position with a child restraint anchor fitting directly behind the seating position. Determine if the vehicle ISOFIX Low Anchorages or Seatbelt will be used to secure the restraint installation. The ISOFLEX connectors will need to be deployed from their storage location prior to adjusting the seat recline angle to rearward facing mode.
  • Page 31 HOW TO INSTALL- PREPARATION INSTALLING INTO VEHICLE REARWARD FACING The restraint is normally packaged in the fully upright forward facing mode. If you need to use it rearward facing you must first fully recline the restraint. Convert the restraint to rearward facing mode by referring to steps below.
  • Page 32 HOW TO INSTALL USING SEATBELT INSTALLING INTO THE CAR USING SEATBELT AND TOP TETHER Pull to lengthen Prepare the child seat by placing into recline mode as detailed on page 31 'INSTALLING INTO VEHICLE REARWARD FACING'. Push A. Lengthen the harness by pressing the Harness harness adjustment button while pulling both Adjustment...

  • Page 33: How To Install Using Seatbelt

    HOW TO INSTALL USING SEATBELT E. If using a lap-sash seatbelt, open the rearward facing lock-off. Fully lengthen the seatbelt and feed the seatbelt through the seatbelt path slot and across the seat surface below the crotch buckle and straps under the comfort pad and through the opposite slot.
  • Page 34 HOW TO INSTALL USING SEATBELT G. Refit the comfort foam over the tensioned seatbelt installation. For smaller babies replace the Infant Safety Cushion™. Some models may utilise the Flexi Infant Safety Cushion which utilises detachable side panels. Do not use the Infant Safety Cushion™ if the child's shoulders reach the lower shoulder height marker unless the side panels are detachable.
  • Page 35 HOW TO INSTALL USING ISOFLEX CONNECTORS INSTALLING INTO THE CAR USING ISOFLEX CONNECTORS AND TOP TETHER To prevent damage to vehicle seat it may be necessary to remove or open a trim covering the ISOFIX low anchorages. A. Locate the ISOFIX Lower Anchorages in the vehicle seat bight. The location may be identified by one of the following symbols, or the anchorage bars may be visible.

  • Page 36: How To Install Using Isoflex Connectors

    HOW TO INSTALL USING ISOFLEX CONNECTORS USING ISOFLEX AND TOP TETHER CONNECTORS A. With the restraint upright, remove both ISOFLEX connectors from storage location on the rear of the restraint by lifting the cover flap as shown. Close the cover flaps. B.
  • Page 37 HOW TO INSTALL USING ISOFLEX CONNECTORS F. Engage the ISOFLEX connectors with each ISOFIX low anchorage. A click may be heard and a green indicator will show on the top of the ISOFLEX connector when it has engaged. Pull each strap to ensure both lower anchorage connectors are engaged.
  • Page 38 HOW TO INSTALL TOP TETHER The following will usually be done once the child has Fully press top tether Adjuster Button been harnessed into the seat. (A) while pulling top tether Strap (B) to A. Lengthen the top tether strap by pressing the lengthen.

  • Page 39: How To Install Top Tether

    HOW TO INSTALL TOP TETHER (SEATBELT INSTALLATION) Ensure the top tether strap is tightened, attached to the upper anchorage point and that the straps are the same Attachment Clip length on both sides of attachment clip. See fitting the top tether, on page 35.
  • Page 40 HOW TO INSTALL TOP TETHER (ISOFLEX INSTALLATION) Ensure the top tether strap is tightened, attached to the Attachment Clip upper anchorage point and that the straps are the same length on both sides of attachment clip. See fitting the top tether, on page 34.
  • Page 41 HOW TO INSTALL TOP TETHER If the car's child restraint anchor fitting is behind the vehicle seatback you may need to use an extension strap as part of the top tether installation. IMPORTANT: If using an Extension Strap, positioning the attachment clip above the child may lead to injury in an accident therefore make sure that the attachment clip is not positioned in front of the vehicle seat.
  • Page 42 HOW TO INSTALL TOP TETHER ANGULAR ADJUSTMENT OF RESTRAINT Some vehicle seats have more rearward slope than others. If the angle of the seat causes the child to be too upright for comfort, the angle may be altered by placing firm packing between the seat and the underside of the base.
  • Page 43 HOW TO USE ADJUSTING HARNESS POSITION & HEADREST HEIGHT REARWARD-FACING MODE Correct fitment of the harness is very important as it restrains the child in the seat. The headrest must be in the correct position and the harness must fit firmly around upper torso of the child and be positioned so as to leave the child's arms and legs free.
  • Page 44 HOW TO USE The shoulder straps must be in the slots which are nearest to the child's shoulders, but not lower than the child's shoulders. There is only one set of slots. The slots move with the headrest, therefore the headrest position must always be checked and adjusted to the correct position.
  • Page 45 HOW TO USE ADJUSTING AHR EASY ADJUST™ HEADREST AND HARNESS STRAP HEIGHT You do not need to remove the restraint from the vehicle to adjust the harness or headrest positions. A. Small adjustments may be made with the child in the seat, the child will need to lean forward to allow Pull to lengthen the headrest to be adjusted.
  • Page 46 HOW TO USE PLACING CHILD INTO RESTRAINT A. Ensure the headrest and shoulder straps are adjusted to the correct height for your child (see page 45). B. Lengthen the top tether strap and allow the straps to fall to the sides of the restraint for easier access to the child.
  • Page 47 HOW TO USE IMPORTANT : Always adjust the height of the shoulder straps as the child grows. CAUTION: Do not harness an infant wrapped in a blanket or swaddled as this increases the risk of ejection and injury or death in a crash. The harness needs to fit firmly to the baby, any blanket or other covering may be placed over the harness after the harness is adjusted.
  • Page 48 Make sure that nothing is obstructing harness straps and that child’s arms and legs are free with the straps in the correct location - see previous page. Do not use the restraint if straps do not tighten and contact BRITAX Customer Service. Refer to back cover for contact details.
  • Page 49 HOW TO USE H. Tighten the top tether strap by pulling the adjustment strap. Ensure the strap is not so tight as to lift the child seat or deform the headrest. Press Pull Adjustment Strap to remove slack I. Always roll up excess strap and place in the Roll up excess strap and pocket provided attached to the cover.
  • Page 50 HOW TO REMOVE REMOVE RESTRAINT FROM VEHICLE Fully press Adjuster Button (A) while DISCONNECT TOP TETHER AND SEATBELT pulling Top tether Strap (B) to lengthen. A. Disengage the vehicle seatbelt buckle and lock-off devices. Remove vehicle seatbelt from the restraint belt paths.

  • Page 51: How To Remove

    HOW TO REMOVE DISCONNECT TOP TETHER AND Fully press Adjuster Button (A) while pulling ISOFLEX CONNECTORS Top tether Strap (B) to lengthen. A. Remove the top tether strap from storage pocket. Fully press top tether adjuster button (A) while pulling top tether strap (B) to lengthen as shown. In some vehicles loosening of the top tether strap may be difficult.
  • Page 52 HOW TO REMOVE D. To store the stabilising bar; place seat in the upright position. Lift the front flap at the end of the seat, to Stabilising uncover the stabilising bar storage recess. E. Press the button on left side (facing seat), to unlock Front stabilising bar.
  • Page 53 NOTES Instructions for Installation & Use...
  • Page 54 FEATURES: FORWARD-FACING Shoulder height markers are exposed as the headrest is raised. 1. AHR Easy Adjust Headrest lever 2. AHR Easy Adjust Headrest (with SICT™) 3. Padded cover for comfort (may vary in style) Harness Tongues 4. Harness Tongue holders 5.

  • Page 55: Features: Forward-Facing

    FEATURES: FORWARD-FACING FORWARD-FACING BELT PATH 11. Rear facing Lock-off 16. Yellow labels 12. Recline Latch 17. Forward facing sash belt lock-off 13. Release Latch 18. Top Tether Storage Pocket 14. Base (shown in forward facing mode) 19. Vehicle Upper Anchorage fitting 15.
  • Page 56 FEATURES: FORWARD-FACING Shoulder height markers are exposed as the headrest is raised. 1. AHR Easy Adjust Headrest lever 2. AHR Easy Adjust Headrest 3. Side Impact Cushion Technology™ (SICT™) 4. Shoulder Pads 5. Harness Tongue holders Harness Tongues 6. Flexi Infant Safety Cushion™ (centre panel only) 7.
  • Page 57 FEATURES: FORWARD-FACING FORWARD-FACING BELT PATH 13. Rear facing Lock-off 18. Yellow labels 14. Recline Latch 19. Forward facing sash belt lock-off 15. Release Latch 20. Top Tether Storage Pocket 16. Base (shown in forward facing mode) 21. Vehicle Upper Anchorage fitting 17.
  • Page 58 ISOFLEX FEATURES: FORWARD-FACING ISOFIX COMPATIBLE 26. ISOFLEX Connector Release Button 27. ISOFLEX Connector 28. ISOFLEX Strap Adjuster 29. ISOFLEX Strap Adjuster Button 30. ISOFLEX Strap 31. Tension Indicator (Green when activated) 32. ISOFLEX storage cover ISOFLEX Connectors are located under the storage covers 33.
  • Page 59 SUITABLE FOR USE Once the child's shoulders reach the lower or middle shoulder height marker then the seat can be changed to the forward-facing position and used until the child's shoulders reach the upper shoulder height marker. Continue to use this restraint in this forward-facing mode until the child's shoulders reaches the limit of the upper shoulder height marker.
  • Page 60 HOW TO INSTALL - PREPARATION INSTALLING INTO VEHICLE FORWARD FACING (UPRIGHT OR RECLINED) A. Store the stabilising bar by lifting the front flap at the end of the seat to uncover the stabilising bar Stabilising storage location. C. Press the blue button on left side (facing seat), to Front unlock the stabilising bar.

  • Page 61: How To Install Preparation

    HOW TO INSTALL - PREPARATION E. If previously used in rearward facing mode, convert the restraint to forward facing mode by placing one hand over rear corner of the base and lift the top end of restraint with the other hand until audible click is heard.
  • Page 62 HOW TO INSTALL - PREPARATION H. Position the restraint in forward-facing mode and FULLY UPRIGHT CHILD USE MODE align restraint centrally to the chosen seating position. I. Adjust recline as required prior to installation. Some vehicle seat fabrics (particularly velours) may be damaged by a child restraint used continuously.
  • Page 63 HOW TO INSTALL USING SEATBELT INSTALLING INTO THE CAR USING SEATBELT AND TOP TETHER A. Fully lengthen seatbelt. Thread the seatbelt into forward facing seatbelt path (yellow marker) as shown below, ensuring that the seatbelt is behind the harness straps and that the lap part of the seatbelt is below the hook as shown below, on each side.
  • Page 64 HOW TO INSTALL USING ISOFLEX CONNECTORS INSTALLING INTO THE CAR USING ISOFLEX AND TOP TETHER To prevent damage to vehicle seat it may be necessary to remove or open a trim covering the ISOFIX low anchorages. A. Locate the ISOFIX Lower Anchorages in the vehicle seat bight. The location may be identified by one of the following symbols, or the anchorage bars may be visible.
  • Page 65 HOW TO INSTALL USING ISOFLEX CONNECTORS C. Recline instructions are shown on page 60. D. Press and hold the ISOFLEX strap adjuster button and pull the connector strap to fully lengthen. Repeat for both connector straps. E. Place the restraint in the desired location on the vehicle seat between the two ISOFIX low anchorages.
  • Page 66 HOW TO INSTALL TOP TETHER D. Fit the top tether attachment clip to the anchor fitting as Top tether attachment clip shown. Make sure to remove as many twists as possible from the top tether strap. Refer to the car owners handbook for the location of the child restraint upper anchorage fitting.
  • Page 67 HOW TO INSTALL TOP TETHER IMPORTANT : Always secure the loose end of the top tether strap to prevent it hanging out of the car or being accessible by the child. THIS RESTRAINT IS NOT SUITABLE FOR USE WHERE THE TOP TETHER STRAP MAY FALL INTO A SPLIT IN THE SEAT BACK OR OFF THE SIDE OF THE SEAT.
  • Page 68 HOW TO INSTALL TOP TETHER Attachment Clip Car's Upper Anchorage Fitting Front of Vehicle Remove slack, then store the excess Top tether strap strap as shown Pull to Excess Top tighten belt Tether Strap Top tether storage Seatbelt lock-off pocket Forward facing seatbelt path Hook...
  • Page 69 HOW TO INSTALL TOP TETHER Attachment Clip Car's upper anchorage point DO NOT USE RESTRAINT IN REARWARD FACING MODE WITHOUT STABILISING BAR FULLY EXTENDED. THE TOP TETHER STRAP MUST ALWAYS BE FITTED WHEN THE CHILD RESTRAINT IS USED IN A VEHICLE. ALWAYS ATTACH THE HOOK AND REMOVE THE SLACK.
  • Page 70 HOW TO USE ADJUSTING HARNESS POSITION & HEADREST HEIGHT FORWARD-FACING MODE Correct fitment of the harness is very important as it restrains the child in the seat. The headrest must be in the correct position and the harness must fit firmly around upper torso of the child and be positioned so as to leave the child's arms and legs free.
  • Page 71 HOW TO USE ADJUSTING AHR EASY ADJUST™ HEADREST AND HARNESS STRAP HEIGHT You do not need to remove the restraint from the vehicle to adjust the harness or headrest positions. A. Small adjustments may be made with the child in Pull to lengthen the seat, the child will need to lean forward to allow the headrest to be adjusted.
  • Page 72 HOW TO USE PLACING CHILD IN THE RESTRAINT A. Ensure the headrest and shoulder straps are adjusted to the correct height for your child (see page 70). Release and lengthen the shoulder straps by pressing the harness adjuster and pulling both shoulder straps evenly. Pull out to the lengthen.
  • Page 73 - see previous page. Do not use the restraint if straps do not tighten and Pull Adjustment Strap contact BRITAX Customer Service. Refer to back to tighten the harness cover for contact details. Instructions for Installation & Use...
  • Page 74 HOW TO REMOVE REMOVING CHILD FROM RESTRAINT A. Push and hold the harness adjustment button while pulling both shoulder harness straps to release and lengthen the harness to the desired amount. B. Press the red button on harness buckle, both harness tongues will be released.
  • Page 75 HOW TO REMOVE DISCONNECT SEATBELT INSTALLATION A. Disengage the seatbelt lock-off devices on both sides of the restraint. B. Disengage seatbelt tongue from buckle and remove the seatbelt from the restraint belt paths. Allow seatbelt to feed back into seatbelt retractor. DISCONNECTING THE ISOFLEX CONNECTORS A.
  • Page 76 HOW TO INSTALL IN AN AIRCRAFT HOW TO INSTALL USING AIRCRAFT LAP BELT - FORWARD FACING NOTE: ONLY CHILD RESTRAINT WITH GREEN AIRCRAFT LABEL ARE SUITABLE FOR USE ON AN AIRCRAFT WHEN INSTALLED FORWARD FACING. The child restraint must be used in accordance with the aircraft procedures, and any directions from the aircraft operator, pilot or crew.

  • Page 77: How To Install In An Aircraft

    HOW TO INSTALL IN AN AIRCRAFT C. Fully lengthen lap belt. Thread the lap belt into BELT PATH - FORWARD FACING lap belt path (yellow marker) as shown, ensuring that the lap belt is behind the harness straps and that the lap part is below the hook as shown, on each side.
  • Page 78 D. Ensure the buckle is free of fluff, liquid or other matter that may enter the buckle slots. Clean the buckle if it is sluggish to engage. See next page. E. If any part of the restraint is cracked or broken, seek repair immediately - contact Britax Customer Service 1300 303 330 CLEANING CAR SEAT Use only mild soap and water to clean all metal and plastic parts of the restraint.

  • Page 79: Care & Maintenance

    D. Refit the harness buckle to the restraint ensuring the red button facing outwards and the 3-bar slide is fed through the same slots. If the Harness Buckle cannot be returned to its original working condition then contact BRITAX Customer Service for assistance. Instructions for Installation & Use...
  • Page 80 CARE & MAINTENANCE TO CLEAN COVER (STYLE MAY VARY) For machine washable covers use gentle cycle, cold water only, rinse well and dry on a flat surface. Do not tumble dry, bleach or dry-clean. May be hand washed. Follow the care label on the cover.
  • Page 81 CARE & MAINTENANCE TO REPLACE SHOULDER STRAPS This restraint is fitted with a harness system that does not need to be removed to adjust the harness or remove the cover. If the harness straps have been removed from the metal strap Headrest Locking Bar connector: A.
  • Page 82 CARE & MAINTENANCE E. To remove the cover, unhook elastic loops from behind the restraint. Unhook elastic loops from the front of the restraint underneath the stabilising bar. If fitted with SICT- remove plastic flaps from the both sides of the cover (next to air cushion). Peel away from restraint while feeding through the harness adjuster button moulding, harness tongues and Unhook elastic loops from the back of...
  • Page 83 F. Refit any Flexi / Infant Safety Cushion™ see page 83, shoulder pads and Ezy Buckle System as required. See page 84 for suitability. G. Ensure none of the harness straps are twisted. ONLY USE BRITAX SAFE-N-SOUND SEAT COVERS THAT ARE DESIGNED AND TESTED FOR USE WITH THIS PRODUCT. VERY IMPORTANT :...
  • Page 84 ACCESSORIES PADDED INSERTS There are 2 types of padded inserts. The Infant Safety Cushion™ Is designed to snugly support baby for extra comfort and must be used for small babies when Rearward-Facing. Discontinue use when the Infant Safety Cushion™ insert is a tight fit or creates discomfort for larger babies.

  • Page 85: Accessories

    If an aftermarket accessory is used that is not recommended by Britax, ensure that the accessory is for this restraint and compliant with AS/NZS 8005 and stated as suitable for use with this child restraint.
  • Page 86 ACCESSORIES EZ BUCKLE SYSTEM EZ Buckle system retains the harness buckle in a forward position and prevents the child from sitting on the buckle when boarding. Aids in opening harness and placing child in the seat. A. Feed EZ Buckle system though slot in front of crotch buckle slot B.
  • Page 87 ACCESSORIES TOY HOLDER Toy holder The toy holder is located on the side of the cover. Feed through strap and attach hook and loop. Attach Hook Do not attach toys with long straps or cord. The and loop length should not exceed 360mm otherwise the strap or cord could become a strangulation hazard.

  • Page 88: Installation Of Car's Upper Anchorage Point

    INSTALLATION OF CAR'S UPPER ANCHORAGE POINT Consult the vehicle owner’s handbook for location of anchorage fittings or anchorage points and the possible use of spacers. Some vehicles may have an anchor fitting fitted by the vehicle manufacturer. If anchorage points cannot be found refer to car manufacturer or local child restraint fitting station or traffic authority for optimum position of upper anchorage point and the use of spacers.
  • Page 89 INSTALLATION OF CAR'S UPPER ANCHORAGE POINT Extension Straps Length 300mm (Use Britax Safe-n-Sound part 0035). Length 600mm (Use Britax Safe-n-Sound part 0036). Available from all major child restraint retailers. Measure distance from 45° restraint upper anchorage attachment clip to the car anchor fitting.
  • Page 90 INSTALLATION OF CAR'S UPPER ANCHORAGE POINT IF THE CAR IS FITTED WITH CHILD RESTRAINT UPPER ANCHORAGE FITTING UPPER ANCHORAGE POINT Fig.1. Attachment Bolt Locate the upper anchorage point behind the rear seating position. (Consult the car owners handbook for the location of the Lock washer upper anchorage point).
  • Page 91 Centre line of Fig.3. seating position CAR INSTALLATION ACCESSORIES (From retailers of Britax Safe-n-Sound products) EXTRA ANCHOR KITS: Available for using the restraint in additional cars. Re-order no: 0038 EXTENSION STRAPS: May be required for cars without a fixed parcel shelf.

  • Page 92: Travelling Tips

    TRAVELLING TIPS SAFETY Never hold a baby in arms when riding in a motor vehicle. In this position the baby could be thrown against the dashboard, windscreen or other occupant and suffer serious injury or death. When riding in a motor vehicle never nurse a baby and use the same seat belt for both of you. In this position the baby or child could be crushed.

  • Page 93: In Case Of Accident

    NOTICE TO INSURANCE COMPANY CHILD RESTRAINT INVOLVED IN AN ACCIDENT All Britax Safe-n-Sound child restraints are manufactured to Australian/New Zealand Standards AS/NZS1754-2013 which require us to advise users of child restraints to "Destroy the entire restraint if it has been in use in a severe crash, even if no damage is obvious".

  • Page 94: In Case Of Accident

    If you experience an accident you may be eligible for a free replacement. The Britax Safe-n-Sound Crash Exchange Program is a voluntary program designed to ensure that our children are safe and that any seat that may have experienced a severe crash is taken out of the market.
  • Page 95 NOTES Instructions for Installation & Use...
  • Page 96 Scan QR code for Quick Guide and Video installation The Safe-n-Sound trademark and other trademarks are the property of Britax Childcare Pty. Ltd. (Australia). The BRITAX trademark is the property of Britax Childcare Holdings Ltd, UK. We reserve the right to alter this product without notice.
