INSTALLATION OF CAR ANCHOR FITTING
ONLY USE A 5/16 UNC GRADE 5 BOLT. IF THE
BOLT IS NOT THE CORRECT LENGTH THE CAR
MANUFACTURER'S HAND BOOK CAN PROVIDE
ADVICE ON THE CORRECT LENGTH BOLT.
CHILD RESTRAINTS MUST NOT BE ATTACHED TO
UNSOUND METAL OR TO WOOD, OR SYNTHETIC
STRUCTURES. WHEN DRILLING 9 MM HOLE DO
NOT DRILL THROUGH FUEL LINES, FUEL TANKS,
ELECTRICAL WIRING, OR RADIO SPEAKERS.
WEBBING STRAPS MUST BE PROTECTED FROM
SHARP CORNERS AND EDGES. THE ANCHOR
FITTING MUST BE USED ONLY AS DESCRIBED
ABOVE. IT MUST NOT BE HOOKED ONTO ANY
OTHER OBJECT.
CAR INSTALLATION ACCESSORIES
(From retailers of Safe-n-Sound products)
EXTRA ANCHOR KITS: Available for using the restraint in additional cars.
Re-order no: 0038
EXTENSION STRAPS: May be required for cars without a fixed parcel shelf.
Re-order no: 0035 (length 300mm) or
0036 (length 600mm)
GATED 3-BAR SLIDE (Locking clip): For converting lap-sash seat belt to lap belt,
and to obtain a better fit to the car where the fitted lock-off may not be suitable. Most
cars will not need this.
Re-order no: 0215.
Note: Marking on
the top of a Grade 5
Bolt.
Front of Vehicle
200mm
min.
Centre line of
Fig.3.
seating position
57
