SHB211 Socket P Half-Size SBC User's Manual
1.1

Specifications

CPU
®
™
Intel Core
System Chipset
®
Intel GM45 and ICH9M (
CPU Socket
Socket P (478-pin)
Front-Side Bus
800/1066 MHz
BIOS
AMI BIOS via SPI interface with socket
System Memory
Two 204-pin DDR3 SO-DIMM sockets
Maximum up to 8GB DDR3 memory
Supports DDR3 800/1066 memory
L2 Cache: integrated in CPU
Onboard Multi-I/O
Parallel Port: one 26-pin 2.0 pitch box-header for shared
FDD/LPT
Serial Port: one for RS-232/422/485 (COM1) and one port
for RS-232 (COM2)
Two Serial ATA-2 ports
USB Interface
Six USB ports compliant with USB Spec. Rev. 2.0 (two on
the rear I/O, and four ports via wafer connectors)
Expansion Interface
PCIe x16 for discrete graphic card or PCIe x1 deivces
PCIe x4 for one PCIe x4 or four PCIe x1 I/O Deivces
LPC interface
SSD
CompactFlash
SATA-to-PATA controller
2
®
2 Duo/Celeron M Processors
optional with ICH9M-E)
™
Type-II Socket via jMicron JM20330
Introduction
