SHB211 Socket P Half-Size SBC User's Manual
33
GND
Pin
35
Channel A D2-
37
Channel A D2+
39
GND
2.4.10 LVDS Backlight Connector (CN12)
The 7-pin inverter connector on the SHB211 is with Hirose connector.
The matching connector is strongly recommended to use Hirose DF13-
7S-1.25C.
Pin
1
12V
2
12V
3
5V
4
ENABLE
5
GND
6
GND
7
GND
26
34
GND
Signal
Pin
36
Channel A CLK-
38
Channel A CLK+
40
GND
Signal
Signal
Jumpers and Connectors
