SHB211 Socket P Half-Size SBC User's Manual
VGA Controller
Chipset -- Intel
engine; support Microsoft DirectX 10, Blu-ray 40Mb/s
Memory Size up to 256MB frame buffer sharing system
memory
Maximum Resolution –
CRT – 2048 x 1536 @ 75Hz with 32-bit color
◆
LVDS LCD – 4:3 up to UXGA 1600 x 1200
◆
Digital DisplayPort – 2048 x 1536
◆
Output Interface --
CRT connector for DAC output
◆
DisplayPort connector (co-location with CRT D-Sub 15-
◆
pin connector as an option)
LVDS LCD with single/dual channel 18/24-bit mode
◆
Ethernet
Dual Gigabit Ethernet; 2 x RTL8111B
Serial ATA
Support Serial ATA/Serial ATA II
Two Serial ATA-II ports, 3Gb/s performance and RAID
0,1,5,10 (optional with ICH9M-E)
Audio
®
Intel HD Audio Digital Header
Hardware Monitoring
Support CPU/System temperature, CPU/System voltage,
and CPU/System Smart Fan features
Watchdog Timer
Reset Supported (1-255 level)
Dimensions
185mm x 126mm
Introduction
®
GM45 GMCH Gen5 integrated graphic
3
