2.3

Jumper Settings

Proper jumper settings configure the SHB211 to meet your application
purpose.
Jumper
COM1 Mode Selection
JP1
Default: RS-232
COM1 Mode Selection
JP2
Default: RS-232
COM1 Mode Selection
JP3
Default: RS-232
Audio Speak Out/Line Out Selection
JP4
Default: Line Out
COM2 Mode Select
JP5
COM1 Mode Select
JP6
CF Device
JP8~11
Default: ON
Compact Flash Voltage Selection
JP12
Default: 3.3V
Auto-Power Button Selection
JP13
Default: Manual Power Button
USB1,2 Voltage Selection
JP14
Default: 5V
USB3,4 Voltage Selection
JP15
Default: 5V_SBY
Digital Displayport only or concurrent with
PCIE (SHB211 PGGA )
JP16
Default: Digital Displayport concurrent with
PCIE
USB5,6 Voltage Selection
JP17
Default: 5V_SBY
LVDS Voltage Selection
JP18
Default: 3.3V
Normal Operation/Clear CMOS setting
JP19
Default: Normal Operation
10
Default Setting
COM2 Pin 1: DCD
COM2 Pin 8: RI
COM1 Pin 1: DCD
COM1 Pin 8: RI
Jumpers and Connectors
Jumper Setting
Short 1-2
Short 3-5, 4-6
Short 3-5, 4-6
Short 1-3, 2-4
Short 7-9
Short 8-10
Short 7-9
Short 8-10
Short 1-2
Short 1-2
Short 1-2
Short 1-2
Short 2-3
Short 1-2
Short 2-3
Short 1-2
Short 1-2
