Parallel Port Address
Parallel Port Mode
Select an operating mode for the onboard parallel
(printer) port.
Parallel Port IRQ
Use this item to set up the IRQ for onboard parallel port.
Hardware Health Configuration
This screen shows the Hardware Health Configuration, and a
description of the selected item appears on the right side of the
screen.
H/W Health Function
You can select this item Enabled for the Hardware Health
Monitoring Device. The Hardware Health Event Monitoring
displays the temperature of CPU and System, Fan Speed,
Vcore, etc.
SYSFAN/CPUFAN/AUXFAN Mode Setting
These items can enable or disable the Smart Fan to adjust
the CPU/system fan speed automatically in accordance
with the current CPU temperature that can prevent the
AMI BIOS Setup Utility
SHB211 Socket P Half-Size SBC User's Manual
49
