SHB211 Socket P Half-Size SBC User's Manual
CHAPTER 4 HARDWARE DESCRIPTION
4.1
Microprocessors
The SHB211 Series supports Intel
processors, which make your system operated under Windows
and Linux environments. The system performance depends on the
microprocessor. Make sure all correct settings are arranged for your
installed microprocessor to prevent the CPU from damages.
4.2
BIOS
The SHB211 Series uses AMI Plug and Play BIOS with a single 8Mbit
SPI Flash.
4.3
System Memory
The SHB211 Series supports two 204-pin DDR3 DIMM sockets for a
maximum memory of 8GB DDR3 SDRAMs. The memory module can
come in sizes of 64MB, 128MB, 256MB, 512MB, 1GB and 2GB.
36
®
™
Core
2 Duo/Celeron
Hardware Description
®
M
®
XP
