AXIOMTEK SHB211 Series User Manual page 93

29 REFCLK0+ GND
30 REFCLK0- GND
31 GND REFCLK1+
32 RSVD REFCLK1-
33 REFCLK2+ GND
34 REFCLK2- GND
35 GND REFCLK3+
36 RSVD REFCLK3-
37 REFCLK4+ GND
38 REFCLK4- GND
39 GND N.C
40 RSVD N.C
41 N.C GND
42 N.C GND
43 GND N.C
44 GND N.C
45 a_PETp0 GND
46 a_PETn0 GND
47 GND a_PERp0
48 GND a_PERn0
49 a_PETp1 GND
50 a_PETn1 GND
51 GND a_PERp1
52 GND a_PERn1
53 a_PETp2 GND
54 a_PETn2 GND
55 GND a_PERp2
56 GND a_PERn2
57 a_PETp3 GND
58 a_PETn3 GND
59 GND a_PERp3
60 GND a_PERn3
61 a_PETp4 GND
62 a_PETn4 GND
63 GND a_PERp4
PICMG v1.3 Interface Definition
SHB211 Socket P Half-Size SBC User's Manual
29 N.C
30 N.C
31 N.C
32 N.C
33 N.C
34 N.C
35 N.C
36 GND
37 GND
38 N.C
39 N.C
40 GND
41 GND
42 +3.3V
43 +3.3V
44 +3.3V
45 +3.3V
46 +3.3V
47 +3.3V
48 +3.3V
49 +3.3V
50 +3.3V
51 GND
52 GND
53 GND
54 GND
55 GND
56 GND
57 GND
58 GND
59 +5V
60 +5V
61 +5V
62 +5V
63 GND
GND
GND
N.C
N.C
N.C
GND
GND
N.C
N.C
GND
GND
N.C
N.C
+3.3V
+3.3V
+3.3V
+3.3V
+3.3V
+3.3V
+3.3V
+3.3V
+3.3V
GND
GND
GND
GND
GND
GND
GND
GND
+5V
+5V
+5V
+5V
GND
87
