Configuring Internet Explorer For Proxy Mode - EdgeWave iPrism Web Security Administration Manual

iPrism
In the menu bar at the top of the window, click Advanced.
4.
Click Change Settings (next to the Proxies label).
5.
Check Web Proxy (HTTP) .
6.
In their respective fields next to that check box, type the IP address or hostname of the iPrism
7.
and default port 3128.
Note: If you changed the iPrism's default proxy port, type that port number
instead.
Click Apply Now.
8.

Configuring Internet Explorer for Proxy Mode

From within Internet Explorer, select the Tools menu, then select Internet Options.
1.
Select the Connections tab.
2.
Click LAN Settings to open the Local Area Network (LAN) Settings dialog box.
3.
In the Proxy Server frame, check Use a proxy server.
4.
In the Address field, enter the IP address that you assigned to your iPrism server. (You do not
5.
need to include the http://.)
In the Port field, enter 3128.
6.
Note: If you want to manually specify the proxy address and port settings for
each protocol (FTP, HTTP, etc.), click Advanced and type the information in
the Proxy Settings dialog box. Uncheck the Use the same proxy server for all
protocols checkbox, and type the iPrism IP address in the HTTP, Secure, FTP,
and Gopher fields. Assign each line the Port value "3128".
Click OK.
7.
If you do not want iPrism to filter local (e.g., Intranet) traffic, check Bypass proxy server for
8.
local addresses.
Click OK.This browser is now configured to authenticate through iPrism.
9.
Appendix B Configuring Browsers for Proxy Mode
Administration Guide
194
