Configuration Port: 80 is the default port used to access iPrism administration tools. The port can be
any value between 1 and 65,535, but cannot be the same as either of the proxy ports.
After changing the configuration port, you will need to append the port number to your iPrism URL to
access the iPrism configuration tools, for example:
https://[your iPrism]:8080
To add a proxy or configuration port:
From the iPrism home page, select System Settings, then select Ports.
1.
To enter a proxy or configuration port, type the port number in the Proxy Port or Configuration
2.
Port field.
Click Save.
3.
If you have completed all your administrative changes, click Activate Changes to activate the
4.
changes immediately. If you do not Activate Changes now, you will be prompted to do so before
logging out of iPrism.

Redirect and HTTPS Ports

Bridge (transparent) mode redirect ports: This setting is no longer used. iPrism does HTTP filtering
on all ports by default.
Proxy mode HTTPS ports: By default, iPrism only allows access to secure ports 443 and 563. If
using Proxy mode, and you require access to secured sites on other ports, you can define them here
as described below.
To add, edit or delete a redirect port (Bridge (transparent) mode only):
From the iPrism home page, select System Settings, then Ports.
1.
To add a redirect port (Transparent mode only), click Add.
2.
Type the port number you want to use and click OK.
3.
To edit a redirect port (Transparent mode only), select the port in the Redirect Ports list and click
4.
Edit.
Make your changes and click OK.
5.
