- Page 1 Hardware Guide iPrism Web Security 800-782-3762 www.edgewave.com...
- Page 2 © 2001 – 2008 St. Bernard Software Inc. All rights reserved. The St. Bernard Software logo, iPrism, iGuard and ERS are trademarks of St. Bernard Software Inc. All other trademarks and registered trademarks are hereby acknowledged. Other product and company names mentioned herein may be the trademarks of their respective owners.
- Page 3 Contents ERS Hardware ........................4 Front and Back Covers..................... 4 LEDs and Lights ....................... 5 Power Supplies ........................ 6 Installing the ERS M6200 Appliance ................6 Contacting St. Bernard Software Technical Support ............. 7 ERS Hardware Guide...
- Page 4 ERS Hardware Front and Back Covers Figure 1: ERS M6200 with cover installed Figure 2: ERS M6200 Front Panel (with cover removed) ERS Hardware Guide...
- Page 5 LEDs and Lights • Ethernet Interface #1/#2 Activity Light: Blinking green indicates that data is passing through the management interface. Steady green indicates the management interface is connected. • On/Off Switch: When power is not applied to the system, press this switch to power the ERS appliance.
- Page 6 • Ethernet Interface #1: This RJ45 connector provides auto-sensing Gigabit Ethernet connectivity to your local network. • Ethernet Interface #2: This RJ45 connector provides auto-sensing Gigabit Ethernet connectivity to your local network. Not normally used. • Power Supply LED: Indicates that the individual power supply is turned on and operational.
- Page 7 Contacting St. Bernard Software Technical Support Phone and email support: Weekdays, 12:00 Midnight – 4:00 p.m. Pacific Time (8:00 a.m. to 12:00 Midnight GMT) To contact Technical Support online, visit http://www.stbernard.com/products/support/iprism/support_iprism-6-0.asp and fill out the Support Request Form. iPrism Phone Numbers: Tel: 1-858-676-5050 Fax: 1-858-676-5055 Chat support:...
