PROGRAMMING

Programming can be carried out either by text message or by dialling into the intercom
panel (Certain programming features can only be setup by text message).
IMPORTANT NOTE: When you are required to use " in a text message it is very important to use the
correct symbol and not for example ' (Or two ' single apostrophes side by side which you will see
look the same but will be interoperated differently by the SMS intercom panel).

PROGRAMMING BY TEXT MESSAGE

Programming by text message is the simplest way to customise the settings of the
intercom panel and add or delete telephone numbers. Simply send texts in the format
below to the telephone number of the SIM within the intercom panel:-
<4 DIGIT CODE><3 DIGIT FUNCTION CODE><OPTIONAL DATA><OPTIONAL ?>
4 DIGIT CODE:
3 DIGIT FUNCTION CODE:
DESCRIPTION
Store a telephone no.
Set call time
Set relay time
Set auxiliary out time
Set auxiliary out mode
Keep connection facility
Divert to second no. time
Enable/disable divert
Check GSM signal strength
Check software version
Dial a number
Store SMS message for C2-AI
Change 4 digit code
Initiate a special command
Trigger the relay
Trigger the auxiliary output
Store balance check dial string
Check credit balance
Latch the relay
Unlatch the relay
Latch the auxiliary output
Unlatch the auxiliary output
OPTIONAL DATA:
PAGE 17 of 36
The code prevents unauthorised access to the programmable
features of the system. The code must be four digits long but
can be any combination using digits 0 – 9. The default code is
1111 and will be used for all examples in this manual.
The 3 digit function code identifies the programmable feature
to be changed. The code must be in capital letters. The table
below lists the available codes.
CODE EXAMPLE
STN 1111STNnnn"01912243174"
SPT 1111SPTnn
RLT 1111RLTnn
AOT 1111AOTnn
AOM 1111AOMnn
NOD 1111NODnn
DIT 1111DITnn
DIV 1111DIVnm
SIG 1111SIG?
VER 1111VER?
DLE 1111DLE"123"
SMS 1111SMS"HouseAlarm"
CDE 1111CDE1234
PRG 1111PRG(command)
RLY 1111RLY
AUX 1111AUX
SDL 1111SDL"*#1345#"
BAL 1111BAL?
RLA 1111RLA
RUL 1111RUL
ALA 1111ALA
AUL 1111AUL
The optional data will vary depending on the command used.
It may be a telephone number, a time setting or may not be
used at all. For more information see the command settings
below.
VR GSM DOOR INTERCOM TECHNICAL MANUAL
SETTINGS DEFAULT
nnn = 001-250 N/A
nn = 01 - 12 02 (40s)
nn = 00 - 99 05 (5s)
nn = 00 - 99 05 (5s)
nn = 00 or 01
nn = 01 - 99 30 (30days)
nn = 01 - 99 15 (15s)
n = 0-9 m = 0-1 m = 0
N/A N/A
N/A N/A
N/A N/A
N/A AUX TRIG
Any 4 digits 1111
AT commands N/A
N/A N/A
N/A N/A
N/A N/A
N/A N/A
N/A N/A
N/A N/A
N/A N/A
N/A N/A
PAGE
19-20
20
21
21
01 21-22
22
22
22-23
28-29
28
23
23
22
24
28
28
24
28-29
28
28
28
28
