STORING A TELEPHONE NUMBER FOR DIAL IN DOOR RELEASE
Dial in door release allows users of telephones with their number stored to release the
door/gate simply by dialling the telephone number of the SIM in the intercom panel. The
intercom panel will check the callers ID when it receives a call and if it matches the list of
stored numbers, it will clear the call down (Avoiding the caller being charged for the call)
and will activate the relay for the programmed time. The number of numbers thatcan be
stored depends on the SIM card's available memory. SIM cards are normally able to store
100 – 250 numbers. The messages to check, store or delete numbers are as follows (See
important note on page 18):-
1111STNnnn"yyyyyyyyyyy"
1111STNnnn"yyyyyyyyyyy"?
1111STNnnn?
1111STNnnn#
1111STNnnn#?
Memory location nnn can be in the range of 100 – 250. (Important note: Some SIM cards
may use some of the memory locations for special features such as checking balance,
retrieving voice mails etc. If you are not planning to use all memory location we would
suggest storing from location 111 onwards. Use the chart on page 26-27 to record the
telephone numbers stored.
Note: It is important to switch off voicemail and automatic SMS features on the SIM
card when using this feature. See the 'Forced Dial' section for more details. Also
note that it will not be possible to use the dial in and program facility from a number
stored to release the door/gate when dialling in.
SET CALL TIME
The call time is the maximum time in seconds that a call can last before the intercom panel
automatically clears the call down. The time can be from 20 seconds up to 240 seconds (4
minutes) and begins from when the call button is pressed. The default time is 40 seconds.
The following messages are used to set/check the maximum call time.
1111SPTnn
PAGE 19 of 36
Store the telephone number yyyyyyyyyyy in position nnn
where nnn = 100 - 250
Store the telephone number yyyyyyyyyyy in position nnn
where nnn =100 - 250and send a confirmation text
message to confirm storage of new number.
Query the telephone number stored in location nnn
where nnn = 100 - 250. A text message will be sent to
the sender with the stored number for that location.
Delete the telephone number stored in location nnn
where nnn = 100 - 250.
Delete and confirm deletion of a telephone number in
location nnn where nnn = 100 - 250.
Store the time nn x 20 seconds (e.g. nn = 03, time = 60
seconds.
VR GSM DOOR INTERCOM TECHNICAL MANUAL
VER2.0.0
