STORING A CALL BUTTON TELEPHONE NUMBER
Telephone numbers can be stored for the ten available call buttons. Each call button can
call up to two telephone numbers (If the first is busy or not answered in a certain time it
can call the second number if the divert facility is setup). The following programming
sequence stores telephone numbers.
nnyyyyyyyyyyy#
nn#
nn can be found using the table. The telephone number y can be a maximum of 19 digits.
Call Button
Button 1 (C1 & a)
Button 2 (C1 & b)
Button 3 (C1 & c)
Button 4 (C1 & d)
Button 5 (C1 & e)
Button 6 (C2 & a)
Button 7 (C2 & b)
Button 8 (C2 & c)
Button 9 (C2 & d)
Button 10 (C2 & e)
Use the chart on page 26 to record the telephone numbers stored.
SET CALL TIME
The call time is the maximum time in seconds that a call can last before the intercom panel
automatically clears the call down. The time can be from 20 seconds up to 240 seconds (4
minutes) and begins from when the telephone rings. The default time is 40 seconds. The
following programming sequence stores a new call time.
50nn#
SET RELAY TIME
The relay time can be from 01 – 99 seconds or latching (Set the relay time to 00 for
latched mode).
51nn#
SET AO (AUXILIARY OUTPUT) TIME
The AO time can be from 01 – 99 seconds or latching (Set the AO time to 00 for latched
mode).
52nn#
CHANGING THE FOUR DIGIT CODE
The four digit code can be any combination of numbers 0-9 but must be 4 digits long. The
code allows access to the programming menu in dial in mode and must be used when
sending text messages to the intercom panel. The following message changes the code:-
59nnnn#
PAGE 25 of 36
Store the telephone number yyyyyyyyyyy in position nn
Delete the telephone number yyyyyyyyyyy in position nn
Memory location (nn) of first
number called
Store the time nn x 20 seconds
Store the time nn = time in seconds.
Store the time nn = time in seconds.
nnnn = new 4 digit code
VR GSM DOOR INTERCOM TECHNICAL MANUAL
Memory location (nn) of divert
01
02
03
04
05
06
07
08
09
10
to number to call
11
12
13
14
15
16
17
18
19
20
(e.g. nn = 3, time = 60 seconds.)
VER2.0.0
