ROBBE-Futaba FX-32 Instruction Manual page 172

Operation modes
The operation modes when stick, trim lever, or
knob was selected are described below.
Linear mode
This mode sets ON/OFF at the left or right (up or
down) with the set point as the reference.
Symmetrical mode
Left and right (up and down) operations are
symmetrical about the neutral position. For
instance, when you want to switch DR1 with the
aileron stick, when the stick is moved to the left or
right, DR1 can be turned on at the same left and
right position.
172 <Data>
Shifting the ON/Off point
The ON/OFF point can be shifted. ON/OFF at
a free position can be changed.
●Black range: OFF range
●White range: ON range
[Setting method]
1. First, use the touch sensor to move the
cursor to the [POSITION] item.
2. Move the stick, trim lever, or knob to the
point you want to change and touch the
RTN button. The point is shifted.
3. To return to the preceeding screen, move
the cursor to the [ON/OFF] at the top of
the screen and touch the RTN button.
