2) Secure the servos with the screws pro-
vided with your radio system.
Throttle servo.
Throttle servo arm.
Steering servo arm.
Steering servo.
Retract servo arm.

INSTALLING THE SWITCH.

Retract servo.
Install the switch into the precut hole in the
side, in the fuselage.
3/ 32" Hole.
THROTTLE SERVO ARM INSTALLATION.
Install adjustable servo connector in the servo
arm as same as picture below:
Adjustable Servo
Loctite secure.
Servo arm.
1
Trim and cut.
2
Diameter= 2mm.
Diameter= 3mm.
7
