4) Locate the plywood battery tray to the
fuselage. Tighten the screws using machine
screws M3x15mm to secure the tray in position.
Battery.
5) Attach the speed control to the side of the
motor box using two-sided tape and tie wraps.
Connect the appropriate leads from the speed
control to the motor. Make sure the leads will
not interfere with the operation of the motor.
Speed control.

INSTALLING THE SPINNER.

Install the spinner backplate, propeller and
spinner cone.
www.seagullmodels.com
M2x6mm.
The propeller should not touch any part
of the spinner cone. If it does, use a
sharp modeling knife and carefully trim away
the spinner cone where the propeller comes
in contact with it.
INSTALLING NOSE RETRACTABLE
LANDING GEAR .
Locate the items ceccessary to install the
Retractable landing gear as shown.
1) Install Retractable landing gear..
