Instruction Manual.
ULTRA JET
4mm.
Blind nut.
M4x60mm.
3) Attach the motor to the front of the electric
motor box using four 3mm blind nut, four
M3x15mm hex head bolts to secure the motor.
Please see picture shown.
M3x15mm.
Electric motor.
10
