Matrix User Guide
3 . 2 I c o n S y m b o l M e a n i n g s
Supply
Ready
Alarm
Tamper
Illuminated
Blinking
Extinguished
Illuminated
Blinking
Extinguished
Illuminated
Blinking
Extinguished
Illuminated
Blinking
Extinguished
Illuminated
Blinking
Extinguished
Illuminated
Blinking
Extinguished
Illuminated
Blinking
Extinguished
Illuminated
Blinking
Extinguished
Illuminated
Blinking
Extinguished
The P1, P2, P3 and P4 icons are used to show partition information as well as the partition segments.
Page 4
Disarmed
(( ))
P1 P2 P3 P4
Partitions
Rest of World
Correct AC & DC power sources
DC source (battery) fault
No AC power supplied to the panel
OK to Arm, no open zones
Select partitions to arm or disarm / Programming function is active
One or more open zones or all assigned partitions are already armed
Used in the Display Log function to qualify log information
Active alarm in FTA mode. Digit display shows active zone
No alarm active
Indicates a tamper condition (used in log display)
Indicates a tamper condition
No tamper alarm active
Indicates a PA alarm condition (used in log display)
Indicates a PA alarm condition
No PA active
Indicates a Fire alarm condition (used in log display)
Indicates a Fire alarm condition
No Fire alarm active
Indicates a system Fault
No Fault active
The panel is armed
The panel is arming with omitted zones
The panel is not armed
The panel is disarmed
The panel is not disarmed
Armed
Personal Attack
Fire
Fault
Denmark, Norway, Finland & Sweden
AC power is OK
An AC fault
No power to panel
RINS915-2
