Matrix User Guide
3 . 8 A r m M o d e s – S i n g l e P a r t i t i o n
Icon Keypad
If a keypad is allocated to only one of the four
available partitions then the arm mode in which this
partition is armed will be displayed, assuming hidden
display mode is not active.
Page 8
If a keypad is allocated to only one of the four
available partitions then the arm mode in which this
partition is armed will be displayed, assuming hidden
display mode is not active.
Alternatively, the arm mode message may be
displayed if enable by your Engineer.
Partition is armed in Mode A
TIME/DATE
ARM MODE
Partition is armed in Mode B
TIME/DATE
ARM MODE
Partition is armed in Mode C
TIME/DATE
ARM MODE
Partition is armed in Mode D
TIME/DATE
ARM MODE
Partition is arming with Omits
TIME/DATE
ARM MODE
LCD Keypad
A
B
C
D
!A
RINS915-2
