Installing The Main Landing Gear - Seagull Models Funfly 3D Assembly Manual

www.seagullmodels.com
wheel.
wheel collar.
Washer.
nut.
Axle.
M3.
M3.
wheel Pant.
Landing Gear.
wheel Pant.
C/A glue. Repeat the process for the other wheel.

INSTALLING THE MAIN LANDING GEAR.

1) The blind nuts for securing the landing
gear are already mounted inside the fuselage.
2) Using the hardware provided, mount the
main landing gear to the fuselage.
M4 x 20mm.
Locker glue.
3) A drop of C/A glue on the wheel collar
screws will help keep them from coming lose
during operation.
9
