AILERON PUSHROD INSTALLATION

Please study images below.
1.
Use a felt tip pen to mark the wire where
it crosses the hole. Use a pair of pliers to
put a shrp 90-degree bend in the wire at
the mark.
2.
3.
4.
Make a 90-degree bend at the mark and
cut of the excess wire leaving 8mm past
the bend.
5.
6.
Connect the linkage as shown and secure
the control wire with a snap keeper.
7.
INSTALLING THE MAIN
LANDING GEAR
NOTE : You must now decide if you will
assemble the Classic Ugly Stick with tri-
cycle landing gear or as a tail dragger. If
you are assembling as a tail dragger, please
skip the nose gear installation steps and
mount the main gear to the FORWARD
mounting location. If you are assembling
using the tricycle landing gear, please
skip the tail wheel installation steps, In-
stall the nose gear, and mount the main
gear to the REAR mounting location.
