Installing The Main Landing Gear - Seagull Models CAP 232 Assembly Manual

CAP 232.
2) Follow diagram below for wheel pant
installation:
7mm.
14mm.
Lite-Plywood
wheel collar.
block.
Axle.
Washer.
Washer.
nut.
wheel Pant.
Lite-Plywood
8
M3.
wheel.
wheel. wheel collar.
Axle.
M3.
block.
Instruction Manual
Landing Gear.
C/A glue.
Locker glue.
3) A drop of C/A glue on the wheel collar
screws will help keep them from coming lose
during operation.
Repeat the process for the other wheel.

INSTALLING THE MAIN LANDING GEAR.

1) The blind nuts for securing the landing
gear are already mounted inside the fuselage.
2) Using the hardware provided, mount
the main landing gear to the fuselage.
Locker glue.
4x20mm.
wheel Pant.
