UICC card

UICC card
UICC card connectors with no cables attached
Connector
J1
J8
UICC card connectors
Connector
J2
J3
J4
J5
J6
J7
Connects to
Speaker
Display
System board
USB to USB port
USB to card reader
USB to system board
5062
5-17
Connector locations
