7.3 Removing a memory card or chart
card
From the homescreen:
1. Select My Data.
2. Select Eject Card.
A message is displayed prompting you to select the memory
device you want to eject.
3. Select SD1 for a memory card in the top card slot, or SD2 for
a memory card in the bottom card slot.
4. Open the chart card door, located on the front right of the
display.
5. Push the edge of the card towards the unit, until an audible
click is heard.
The card is released from the card slot mechanism, as shown
in the following diagram:
6. Use your fingers to pull the card clear of the card slot, using
the edge of the card.
7. To prevent the ingress of water and consequent damage,
close the chart card door.
Note: You can also power off the multifunction display and
follow steps 4 to 7 above.
Managing display data

7.4 Saving user data and user settings

You can save user data (waypoints, routes, and tracks) or user
settings to a memory card for later retrieval.
Type of data
User data (waypoints)
User data (routes)
User data (tracks)
User settings
Note: Raymarine recommends that you save your user data
and user settings to a memory card on a regular basis.
Note: Raymarine strongly recommends that you save
settings to a separate memory card, and NOT to a chart card
containing cartography.
Saving waypoints, routes, and tracks to a
memory card
With the homescreen displayed:
1. Ensure you have a memory card (NOT a chart card) in one
of the card slots.
2. Select My Data.
3. Select Save Data to Card.
If your display has more than 1 card slot then a message is
displayed prompting you to select the memory device you
want to save the data to, if your display only has 1 card slot
then you will not be prompted.
4. Select SD1 for a memory card in the top card slot, or SD2 for
a memory card in the bottom card slot.
5. Select Save Waypoints to Card, Save Routes to Card, or
Save Tracks to Card, as appropriate.
Retrieving waypoints, routes, or tracks from
a memory card
D12291-1
With the homescreen displayed:
1. Ensure you have a memory card containing the user data in
one of the card slots.
2. Select My Data.
3. Select Retrieve from Card.
If your display has more than 1 card slot then a message is
displayed prompting you to select the memory device you
want to retrieve data from, if your display only has 1 card slot
then you will not be prompted.
4. Select SD1 for a memory card in the top card slot, or SD2 for
a memory card in the bottom card slot.
5. Select Retrieve Waypoints, Retrieve Routes, or Retrieve
Tracks, as appropriate.
Erasing waypoints, routes, and tracks from a
memory card
With the homescreen displayed:
1. Ensure you have the memory card containing the data in
one of the card slots.
2. Select My Data.
3. Select Erase from Card.
If your display has more than 1 card slot then a message is
displayed prompting you to select the memory device you
Description Notes
Saves all waypoints to Only 1 waypoints
a single archive file. archive file can be
saved per memory
card.
Saves all routes to a Only 1 routes archive
single archive file. file can be saved per
memory card.
Saves all tracks to a Only 1 tracks archive
single archive file. file can be saved per
memory card.
Saves the settings Only 1 user settings
you've made in the archive file can be
set-up menus to a saved per memory
single archive file. card.
