4.10 SeaTalk connection

You can connect SeaTalk devices to your multifunction display
using the optional SeaTalk to SeaTalk
1
1. SeaTalk device.
2. SeaTalk to SeaTalk ng converter.
3. Multifunction display.
SeaTalk accessories
SeaTalk cables and accessories for use with compatible
products.
Description Part No
3–way SeaTalk D244
junction box
D284
1 m (3.28 ft) SeaTalk
extension cable
3 m (9.8 ft) SeaTalk D285
extension cable
5 m (16.4 ft) SeaTalk D286
extension cable
9 m (29.5 ft) SeaTalk D287
extension cable
E25051
12 m (39.4 ft) SeaTalk
extension cable
20 m (65.6 ft) SeaTalk D288
extension cable
Cables and connections
ng converter.
3
SeaT alk
2
Notes
4.11 New a Series DSC VHF radio
connection
The New a Series multifunction display requires an NMEA 0183
to SeaTalk ng converter and a powered SeaTalk
enable connection to a DSC VHF radio.
NMEA 0183
ng
D12265-1
1 New a Series multifunction display.
2 Actisense NMEA 0183 to SeaTalk
3 NMEA 0183 DSC VHF Radio.
4
SeaTalk
5 Power cable connected to 12 V dc power supply.
1
2
3
4
SeaTalk
ng converter (NGW-1–STNG).
ng terminated 5 way block.
ng backbone to
5
ng
D12743-1
53
