2.5 Touch and non-touch operations
This handbook applies to New a Series, New c Series and New
e Series multifunction displays. All features and functions can be
accessed using physical buttons (non-touch) on New c Series
and New e Series displays or by using the touchscreen on New
a Series and New e Series displays.
This handbook uses icons throughout to identify whether a
particular task is a touch or a non-touch operation.
Touch (Touchscreen operation) — Touch
operations apply to New a Series and New e
Series multifunction displays.
Non-touch (physical button operation) —
Non-touch operations apply to New c Series
and New e Series multifunction displays.
Note: Where a task does not have a touch or non-touch icon
then the task applies to all display variants.
Handbook information
19
