3.2 Installation checklist
Installation includes the following activities:
Installation Task
1
Plan your system.
2
Obtain all required equipment and tools.
3
Site all equipment.
4
Route all cables.
5
Drill cable and mounting holes.
6
Make all connections into equipment.
7
Secure all equipment in place.
8
Power on and test the system.
26
3.3 System Limits
The following limits apply to the number of system components
that can be connected in a Raymarine multifunction display
system.
Component
Maximum number of SeaTalk
hs
devices
Maximum number of SeaTalk
ng
devices
New a Series / New c Series / New
e Series multifunction displays
Maximum
25
50
6
New a Series / New c Series / New e Series
