2.4 Handbook conventions

The following conventions are used throughout this handbook when referring to:
Type Example
Icons
Menus
Applications
Numeric adjust
controls
Slider bar controls
Handbook information
Convention
The term "select" is used in procedures involving icons to refer to the action
of selecting an on-screen icon, either using touch or physical buttons:
• Touch — Press your finger on the icon to select.
• Physical buttons — Use the Joystick to highlight the icon and press
the Ok button.
The term "select" is used in procedures involving menus to refer to the
action of selecting a menu item, either using touch or physical buttons:
• Touch — Press your finger on the icon to select.
• Physical buttons — Use the Joystick to highlight the icon and press
the Ok button.
The term "scroll" is used in procedures involving menus and dialogs to
refer to the action of scrolling a list or menu, either by touch or physical
buttons:
• Touch — Press your finger on the menu and slide up or down to scroll.
• Physical buttons — Turn the Rotary control clockwise or
anti—clockwise to scroll.
.
The term "select" is used in procedures involving applications to refer to
the action of selecting a location, object or target on-screen using touch
or physical buttons:
• Touch — Press and hold your finger on a location to select, or
• Touch — Press and release your finger on an object or target.
• Physical buttons — Use the Joystick to highlight the location, object
or target and press the Ok button.
The term "adjust" is used in procedures involving numerical adjust controls
to refer to the action of changing the numeric value using touch or physical
buttons:
• Touch — Press your finger on the up or down arrow to increase or
decrease the numeric value.
• Physical buttons — Use the Rotary control to increase or decrease
the numeric value.
With the Numeric adjust control displayed you can also select on the
keypad icon or press and hold the Ok button to open a numeric keypad to
enter a new value for the setting.
The term "adjust" is used in procedures involving slider bar controls to
refer to the action of changing the associated numeric value using touch
or physical buttons:
• Touch — Press your finger on the up or down arrow to increase or
decrease the numeric value.
• Physical buttons — Use the Rotary control to increase or decrease
the numeric value.
