Fresh Food Panel:
Step 3
Install
• Start mounting screws through the extrusion and just
mounting
screws
• Stand panel up on the hinge side and hold to access
and handles
• Drive second screw partially into the standoff,
Freezer Drawer Panel:
• Follow the same procedure to assemble handle to
It is best that 2 people perform this step.
Step 4
Install
Fresh Food Panel:
Assembled
• Place assembled panel onto the bottom door trim
Panels
• Push and hold the panel back against the steel door
• Reinstall original screws into the door extrusion.
• Open the door fully to stop.
• Install screws at the top, and hinge side.
Note: The freezer drawer panel should be removed
as shown in the installation instructions for the
ZKTC36 kit. Follow the instructions in Step 1 to
remove the door.
Freezer Drawer Panel:
• Place the assembled panel onto the bottom trim
• Secure the panel to the trim at the bottom and both
• Mount the assembled drawer panel onto the freezer
• Install 4 screws into the top of the handle extrusion
through the custom panel.
the appearance side. Place handle against mounting
screws on the appearance side, drive top screw from
the back of the extrusion partially into the standoff.
alternate back to the top until the handle is tight
against the door.
panel.
with support bracket tabs inserted into slots.
with door handle extrustion flush to the handle side
of the door.
with support brackets inserted into slots. The panel
should be flush with trim on both sides.
sides.
slides. Tighten all screws.
and into the door.
ZKHTCSS1 For 3/4" Panels
Tubular Stainless Steel Handles
Install
4 Screws
38
