Fresh Food Door:
Step 2
Install
• Attach the new 3/4" trim pieces on the top, hinge side
3/4" trim
Freezer Drawer:
• Attach the new 3/4" trim pieces on the bottom and
Step 3 • Position support bracket on the back side of the fresh
Apply panel
support
brackets
• Position support bracket on the back side of the
and bottom using original screws.
both sides.
food panel, 14-5/16" from the hinge side. Secure
support bracket to panel with screws provided.
freezer drawer panel, 14-5/16" from the right side.
Secure support bracket to panel with screws
provided.
ZKTC36L/ZKTC36R Trim Kit
3/4" Custom Panels
Front Face Freezer Drawer
Back Side Fresh Food Panel
Hinge
Support Bracket
Side
14-5/16"
Back Side Freezer Drawer Panel
Support Bracket
14-5/16"
Bottom Edge
Bottom Edge
