Step 4A
Install
handles and
panels
FOR
STAINLESS
STEEL
PANELS
• Crimp top and bottom edges of corrugated.
• Slide corrugated into door and drawer trim. Leave
Note: Panels have a protective plastic covering. Peel
away just enough to allow panel to slide into trim and to
clear handle mounting screws. The plastic covering will
keep the panels clean during the installation process.
Be sure to maintain 1/4" gap between corrugated and
hinge side or bottom trim.
Fresh food door:
• Slide panels into the door trim. Leave about 4" of the
• Place a spacer ring over each of the 2 screw holes
Raised Panel on 1/4" Thick Backing:
A raised panel design secured to a 1/4" thick backing
(screwed or glued) can be used with this handle kit.
• Cut the 1/4" thick panels to size.
• Fabricate the raised panel to allow 1-1/4" clearance
• Allow 5/16" clearance at the other edges to allow for
• Total panel thickness should not exceed 3/4".
• Countertops adjacent to the refrigerator installation
Note: Longer Screws, obtained locally, will be required to
accommodate panel thickness. Use stainless steel
#10-32x1-1/4" truss Phillips head screws.
about 1/4" gap between edge of corrugated and
hinge side trim of the door and 1/4" gap above bottom
trim of the drawer.
panel exposed to allow room to install the handle
extrusion.
on the extrusion. Use tape to hold in place.
from the hinge side of the fresh food panel to avoid
striking adjacent cabinetry.
the trim flange.
should be mitered 45°.
ZKHCSS1 Trim Kit (For 1/4" Panels)
Tubular Stainless Steel Handles
Corrugated
Spacer
Ring
Stainless
Panel
Handle
• Place extrusion onto panel. Use a pencil to punch
hole in tape covering spacer rings and align with
screw holes.
• Install mounting screws through the extrusion and
panel.
• Drive screw part way through the top standoff, then
part way through the bottom standoff.
• Drive both screws until the handles are tight against
the panel.
• Slide the assembly into the door trim until the
extrusion fits firmly against the steel door.
• Reinstall original screws into the door extrusion.
Freezer drawer:
• Follow the same procedure to install spacer ring,
mounting screws and handle to extrusion as de-
scribed for fresh food panel.
• Slide the assembly down into the door trim until the
extrusion fits firmly against the steel drawer.
• Reinstall original screws into the door extrusion.
Raised Panel on 1/4" Thick Backing
Using Standard Handles
1/4"
Appearance
Thick
Panel
Backing
5/16"
Clearance
handle Side
5/16"
Clearance
Handle End
Screw
Extrusion
5/16" Clearance
Fresh Food Panel
1-1/4"
5/16" Clearance
Clearance
hinge side
Freezer Panel
5/16" Clearance
5/16" Clearance
