- Page 1 Design Guide with Installation Instructions 36” Built-In Bottom-Freezer Refrigerators 31-49079-1 224D3095P003 04-15 GE monogram.com...
-
Page 2: Safety
This refrigerator is very heavy. To reduce the risk of person injury during maneuvering and installing this refrigerator, 3 people are required for proper installation. For Monogram local service in your area, call 1.800.444.1845. For Monogram service in Canada, call 1.800.561.3344 For Monogram Parts and Accessories, call 1.800.626.2002. - Page 3 Consignes de Sécurité Ce symbole représente une alerte de sécurité. Ce symbole vous avise de dangers possibles pouvant causer la mort, des blessures ou autres. Tous les messages de sécurité seront précédés du symbole d’alerte de sécurité ainsi que des mots « DANGER », «...
-
Page 4: Table Of Contents
Contents Safety 2, 3 Installation Instructions Tools, Hardware, Materials Instructions for Standard Installation 5-19 Grounding the Unit Planning Guide Step 1. Remove Packaging The Installation Space Step 2. Install Water Line Dimensions and Clearances Step 2A. Water Line with Reverse Osmosis System Customization Basics Step 3. -
Page 5: Instructions For Standard Installation
Instructions for Standard Installation... -
Page 6: The Installation Space
Design Guide - Standard Installation DIMENSIONS AND CLEARANCES THE INSTALLATION SPACE 35-1/2" 35" 25-3/8" Finished Width Case Width Case Depth Wall View * Shipping height. The 2-5/16" refrigerator can be adjusted to fit into a 6" ” cutout that is 84-1/2 *84"... -
Page 7: Customization Basics
Design Guide - Standard Installation CUSTOMIZATION BASICS: Optional Accessory Kits Framed Or Overlay Panels, Custom • ZKHCSS2: Monogram Tubular Stainless Steel handles Handles and Accessory Kits designed to fit 3/4” overlay panels. This kit also includes a handle side trim for custom handles. -
Page 8: 1/4" Framed Panel Dimensions
Design Guide - Standard Installation 1/4” FRAMED PANEL DIMENSIONS 5/16" Trim If you choose to install framed panels, they must be cut Door Reveal to the dimensions shown. The panels will slide into the frame on the door, drawer and grille. 1/4"... -
Page 9: Side Panels
Design Guide - Standard Installation SIDE PANELS ZUG2 GRILLE PANEL DIMENSIONS Side panels must be used whenever the sides of the The ZUG2 unified grille panel kit provides for the refrigerator will be exposed. The 1/4 side panels will ” installation of a framed or overlay grille panel. -
Page 10: 130° Door Swing
Design Guide - Standard Installation Frameless Cabinets: The case trim overlaps cabinets at the top and sides. Therefore, frameless cabinets Refrigerator may require filler strips to prevent 23-7/8" From interference with cabinet door swing. Rear of The opening must allow for filler strips. Refrigerator 1"... -
Page 11: Installation Instructions
Installation Instructions - Standard Installation TOOLS REQUIRED MATERIALS REQUIRED • 35” long 2x4 for Anti-Tip support • Tinsnips to cut banding • 1/4” copper water line tubing or GE SmartConnect ™ • Stepladder Refrigerator Tubing kits • Bucket • Water shut-off valve •... -
Page 12: Step 1 Remove Packaging
Installation Instructions - Standard Installation STEP 1 REMOVE PACKAGING • The unit is secured to the skid with 4 slotted tie-down straps. Remove the six 7/16” WARNING Tip Over Hazard. bolts from the base channels The refrigerator is much heavier at the top than at the in the tie-downs. -
Page 13: Step 2A. Water Line With Reverse Osmosis System
Installation Instructions - Standard Installation STEP 4 ANIT-TIP PROCEDURE STEP 2A WATER LINE INSTALLATION WITH A REVERSE OSMOSIS SYSTEM WARNING Tip Over Hazard. Skip this step when not using an RO System These refrigerators are top heavy, especially with any doors open, and must be secured to If the water supply to the refrigerator is from a Reverse prevent tipping forward which could result in Osmosis Water System, use the refrigerator’s filter bypass... - Page 14 Installation Instructions - Standard Installation STEP 4 ANIT-TIP PROCEDURE (CONT) • Hold the metal channel flat against the plastic straps and slide the channel through the hole. • Locate at least 2 studs on the back wall. Mark these • Gently pull back at the ends of the plastic straps to make points on the horizontal line.
-
Page 15: Step 5. Level Unit
Installation Instructions - Standard Installation STEP 5 LEVEL REFRIGERATOR (Cont) STEP 4 ANIT-TIP PROCEDURE (Cont) CONNECT POWER CORD: ATTENTION • Before pushing the refrigerator into the opening, plug the power cord into the receptacle. Open the Les roues de nivellement arrière et les pattes de nivellement avant permettent un réglage maximal de grille panel and reach into the opening at the back 25 mm (1 po). -
Page 16: Step 7 Alternate Anti-Tip Procedure
Installation Instructions - Standard Installation STEP 8 ADJUST DOOR SWING STEP 7 ALTERNATE ANTI-TIP PROCEDURE NOTE: This refrigerator has a 3-position door stop. When space does not allow the door to swing open The refrigerator must be secured to prevent tipping. fully to 115°, you may change the door swing to a 90°... -
Page 17: Step 9 Install Grille Panel
Installation Instructions - Standard Installation STEP 9 INSTALL GRILLE PANEL • Raise the access panel to the stop position. • Loosen the screws on the side trim behind the frame. • Reassemble the bottom trim. Tighten the screws. Remove the bottom trim. •... -
Page 18: Step 10A Install Overlay Panels
Installation Instructions - Standard Installation Right hand models shown. Use the same instructions STEP 10A INSTALL OVERLAY PANELS for left hand models. Use Front Hol to Secure Hand Use Rear Holes to Secure Trim Supplied handle shown in the overlay panel position. Install door and drawer panels: •... -
Page 19: Step 11 Connect Water Supply
Installation Instructions - Standard Installation STEP 12 CONNECT POWER STEP 11 CONNECT WATER SUPPLY • Check to be sure the power cord is plugged into the receptacle. • Check to make sure power to refrigerator is on by opening refrigerator door to see if interior lights are House Refrigerator Water Supply... -
Page 20: Instructions For Flush Installation
Instructions for Flush Installation... -
Page 21: The Installation Space
Design Guide - Flush Installation DIMENSIONS AND CLEARANCES THE INSTALLATION SPACE 39" 35" 25-3/8" Finished Width Case Width Framed Models Wall View 4-5/16" * Shipping height. The refrigerator can be 6" adjusted to fit into a *84" From ” cutout that is 85 max. -
Page 22: 1/2" Overlay Panel Dimensions
Design Guide - Flush Installation 1/2” OVERLAY PANEL DIMENSIONS For a more custom appearance, overlay panels may be installed on trimmed models. The overlay panel must be Door 1/2" secured to a 1/4” thick backer panel which slides into the Overlay trim. -
Page 23: 3/4" Decorative Panel Dimensions
Design Guide - Flush Installation 3/4” DECORATIVE PANEL DIMENSIONS CUSTOMIZATION BASICS: For a more custom appearance, overlay panels may be Framed Or Overlay Panels, Custom installed to give a flush appearance with surrounding cabinets. The overlay panel must be 3/4” thick. Panel Handles and Accessory Kits attaches to included brackets to provide mounting to the These refrigerators are designed to be customized with... -
Page 24: 3/4" Raised Fresh Food Door Panel Routing
Design Guide - Flush Installation 3/4” RAISED FRESH FOOD DOOR PANEL ROUTING For 3/4” raised door panel, routing is required. The router depth is 1/4” all the way around the panel back. Additional panel width reductions are required per the diagrams below. This will create a “picture frame” routing that will slide onto the attached door trim. -
Page 25: 3/4" Raised Freezer Door Panel Routing
Design Guide - Flush Installation 3/4” RAISED FREEZER DRAWER PANEL ROUTING For 3/4” raised door panel, routing is required. The router depth is 1/4” all the way around the panel back. Additional panel width reductions are required per the diagrams below. This will create a “picture frame” routing that will slide onto the attached door trim. -
Page 26: 3/4" Raised Grille Panel Routing
• ZUG2: For side-by-side installation of two trimmed bottom- freezer refrigerators. This kit provides for the installation of • ZKHCSS2: Monogram Tubular Stainless Steel handles a unified custom grille panel to span the width of two units designed to fit 3/4” overlay panels. This kit also includes a using a framed or overlay panel. -
Page 27: Installation
Design Guide - Flush Installation INSTALLATION SIDE PANELS ZUG2 Unified Grille Panel Kit Side panels must be used 24" • If you are installing two units, side by side, the whenever the sides of installation space must be 75” wide. the refrigerator will be Note: Additional cutout width may be required when exposed. -
Page 28: Installation Instructions
Installation Instructions - Flush Installation TOOLS REQUIRED MATERIALS REQUIRED • Tinsnips to cut banding • 35” long 2x4 for Anti-Tip support • Stepladder • 1/4” copper water line tubing or GE SmartConnect ™ • Bucket Refrigerator Tubing kits • Level •... -
Page 29: Step 1 Remove Packaging
Installation Instructions - Flush Installation STEP 1 REMOVE PACKAGING • The unit is secured to the skid with 4 slotted tie-down straps. Remove the six 7/16” WARNING Tip Over Hazard. bolts from the base channels The refrigerator is much heavier at the top than at the in the tie-downs. -
Page 30: Step 2A. Water Line With Reverse Osmosis System
Installation Instructions - Flush Installation STEP 5 ANIT-TIP PROCEDURE STEP 2A WATER LINE INSTALLATION WITH A REVERSE OSMOSIS SYSTEM WARNING Tip Over Hazard. Skip this step when not using an RO System These refrigerators are top heavy, especially with any doors open, and must be secured to If the water supply to the refrigerator is from a Reverse prevent tipping forward which could result in Osmosis Water System, use the refrigerator’s filter bypass... - Page 31 Installation Instructions - Flush Installation STEP 5 INSTALL ANTI-TIP BRACKET (cont.) • Gently pull back at the ends of the plastic straps to • Locate at least 2 studs on the back wall. Mark these points on the horizontal line. make the channel rest flush behind the wall.
-
Page 32: Step 6 Alternate Anti-Tip Procedure
Installation Instructions - Flush Installation STEP 5 INSTALL ANTI-TIP BRACKET (cont.) Remove Grilles for Access to Anti-Tip Locking Hooks Power Cord Fresh Food Unit Locate the power cord inside the left cavity. If it has not • Open the access door. been adjusted so the plug is easily accessible, do so now. -
Page 33: Step 7 Adjust Door Swing
Installation Instructions - Flush Installation STEP 7 ADJUST DOOR SWING STEP 8 INSTALL GRILLE PANEL NOTE: This refrigerator has a 3-position door stop. • Raise the grille panel to stop position. When space does not allow the door to swing open fully to 115°, you may change the door swing to a 90°... -
Page 34: Step 9 Install Door Panels
Installation Instructions - Flush Installation STEP 9 INSTALL DOOR PANELS Install door panel: • Open door to 90°. Remove the 4 Phillips head screws from the door handle. • Remove the handle. Retain all screws. • Remove the 4 screws holding the trim, then lift off the trim. Retain the screws. -
Page 35: Step 10 Connect Water Supply
Installation Instructions - Flush Installation STEP 10 CONNECT WATER SUPPLY STEP 11 CONNECT POWER • Check to be sure the power cord is plugged into the receptacle. House Refrigerator Water Supply Water Suppl • Check to make sure power to refrigerator is on by opening refrigerator door to see if interior lights are on. -
Page 36: Instructions For Stainless Steel Installation
Instructions for Stainless Steel Installation... -
Page 37: The Installation Space
Design Guide - Stainless Steel Installation DIMENSIONS AND CLEARANCES THE INSTALLATION SPACE 35" 35-1/2" 25-3/4" Case Width Finished Width Case Depth Wall View * Shipping height. The 2-5/16" refrigerator can be adjusted to fit into a 6" ” cutout that is 84-1/2 *84"... -
Page 38: Customization Basics
Stainless Steel Wrapped Refrigerators Stainless steel wrapped refrigerators with beveled edges and tubular stainless steel handles that coordinate with other Monogram appliances. These models are shipped REFRIGERATOR LOCATION ready for installation. • Do not install the refrigerator where the temperature Side Panels will go below 55°F (13°C). -
Page 39: 130° Door Swing
Design Guide - Stainless Steel Installation Frameless Cabinets: The case trim overlaps cabinets at the top and sides. Therefore, frameless cabinets Refrigerator may require filler strips to prevent 23-7/8" From interference with cabinet door swing. Rear of The opening must allow for filler strips. Refrigerator 1"... -
Page 40: Installation Instructions
Installation Instructions - Stainless Steel Installation TOOLS REQUIRED MATERIALS REQUIRED • Tinsnips to cut banding • 35” long 2x4 for Anti-Tip support • Stepladder • 1/4” copper water line tubing or GE SmartConnect ™ • Bucket Refrigerator Tubing kits • Level •... -
Page 41: Step 1 Remove Packaging
Installation Instructions - Stainless Steel Installation STEP 1 REMOVE PACKAGING • The unit is secured to the skid with 4 slotted tie-down straps. Remove the six 7/16” WARNING Tip Over Hazard. bolts from the base channels The refrigerator is much heavier at the top than at the in the tie-downs. -
Page 42: Step 2A. Water Line With Reverse Osmosis System
Installation Instructions - Stainless Steel Installation STEP 2A WATER LINE INSTALLATION WITH STEP 4 ANIT-TIP PROCEDURE A REVERSE OSMOSIS SYSTEM WARNING Tip Over Hazard. Skip this step when not using an RO System These refrigerators are top heavy, especially with any doors open, and must be secured to If the water supply to the refrigerator is from a Reverse prevent tipping forward which could result in Osmosis Water System, use the refrigerator’s filter bypass... - Page 43 Installation Instructions - Stainless Steel Installation STEP 4 ANIT-TIP PROCEDURE (CONT) • Hold the metal channel flat against the plastic straps and slide the channel through the hole. • Place the bottom of the wall bracket with tabs on the Plastic Straps horizontal line.
-
Page 44: Step 6 Secure Unit To Wall
Installation Instructions - Stainless Steel Installation STEP 4 ANIT-TIP PROCEDURE (CONT) STEP 6 SECURE UNIT TO WALL Connect Power Cord: • The “L” rod can be found in the upper left corner of the unit in the access compartment. Look through the •... -
Page 45: Step 5. Level Refrigerator
Installation Instructions - Stainless Steel Installation STEP 8 ADJUST DOOR SWING STEP 7 ALTERNATE ANTI-TIP PROCEDURE NOTE: This refrigerator has a 3-position door stop. When space does not allow the door to swing open The refrigerator must be secured to prevent fully to 115°, you may change the door swing to a 90°... -
Page 46: Step 9 Connect Water Supply
Installation Instructions - Stainless Steel Installation STEP 10 CONNECT POWER STEP 9 CONNECT WATER SUPPLY • Check to be sure the power cord is plugged into the receptacle. House Refrigerator • Check to make sure power to refrigerator is on Water Supply Water Suppl by opening refrigerator door to see if interior lights... - Page 47 Notes:...
- Page 48 NOTE: While performing installations described in this book, safety glasses or goggles should be worn. For Monogram local service in your area, call ® 1.800.444.1845. NOTE: Product improvement is a continuing endeavor at General Electric. Therefore, materials, appearance and specifications are subject to change without notice.
