Step 1
• Cut a piece of corrugated to use as a pad to protect
Match Handle
Extrusions
to Panels
• Place custom panels on the pad, appearance side
Note: If panels are wood, be sure to note which end is
the top so that wood grain is in the correct direction on
both sides.
Fresh Food Panel:
Select fresh food handle extrusion for your model, left
• Place extrusion against the handle side of the fresh
• Align the extrusion evenly with the top and bottom of
• Tape the extrusion to the panel to prevent movement.
• Center punch and drill 1/8" pilot holes through the
• Turn panel over. On the appearance side, use 9/32" bit
Freezer Panel:
• Place extrusion against the handle end of the freezer
• Align the extrusion evenly, side to side.
• Tape the extrusion to the panel to prevent movement.
• Center punch and drill 1/8" pilot holes throughout the
• Turn panel over. On the appearance side, use 9/32" bit
• Place a handle standoff on each attachment post on
Step 2
Install
Standoffs
onto Handles
• Install set screws into the bottom of each standoff,
the panel finish. Additional material may be required
to protect flooring when drilling.
down.
or right side extrusion.
food panel.
the panel.
holes in the extrusion and into the panel.
to enlarge clearance hole.
drawer panel.
holes in the extrusion and into the panel.
to enlarge clearance holes.
the handle. Position the screw hole on the standoff
to point to the floor.
using the Allen wrench provided. The standoff
should be tight against the handle.
ZKHTCSS1 for 3/4" Panels
Tubular Stainless Steel Handles
Align ExtrusionEven
With Panel
Back Side Fresh
Food Panel
Back Side Freezer
Drawer Panel
CAUTION: Hole locations must be exact to accept
handle standoff and handle assembly.
Align
Extrusion
Even With
Panel
Screw
Allen Wrench
37
