If you are installing these handles onto Stainless
Step 2A
Steel Panels:
FOR
Use extreme caution if you are drilling through
STAINLESS
stainless steel panels. Stainless steel panels must be
STEEL
handled gently. Do not kneel on stainless steel panels.
PANELS
It will leave a permanent dent. Do not remove protec-
tive plastic covering until final installation.
Fresh food door:
• Place supplied filler panel (corrugated) on floor to use
• On the back side of the panel - at the handle side,
• Slip panel into the new extrusion, flush against inner
• Align extrusion to pencil mark as shown in Step 2.
• Place a handle standoff onto attachment posts along
Step 3
Install
standoffs
onto handles
• Install set screws into the bottom of each standoff,
Fresh food door:
Step 4
Install
• Slide panel into the door trim. Leave about 4" of the
handles
and panels
• Place extrusion onto the back side of the panel, install
FOR CUSTOM
WOOD
PANELS
• Drive screw part way through the top standoff, then
See Step 4A
• Drive both screws until the handle is tight against the
for stainless
steel panels
• Remove tape.
• Slide the assembled panel into the door trim until the
Freezer drawer:
• Slide panel into the drawer trim. Leave about 4" of the
• Place extrusion onto the panel, install mounting
• Drive screw part way through one standoff, then part
• Drive both screws until the handle is tight against the
• Remove tape.
• Slide the assembled panel down until the extrusion
as a pad.
measure and mark 1/4" below the top edge of the
panel.
edge, on the handle side.
Mark each screw hole location with pencil.
the handle. Position the set screw hole on the
standoff to point to the floor.
using the Allen wrench provided. The standoff should
be tight against the handle.
panel exposed to allow room to install the handle
extrusion.
mounting screws through the extrusion and just
through the panel.
part way through the bottom standoff.
panel.
extrusion fits firmly against the steel door. Reinstall
original screws into the extrusion.
panel exposed to allow room to install the handle
extrusion.
screws through the extrusion and just through the
panel.
way through the other standoff.
panel.
fits firmly against the top of the drawer. Reinstall
original screws into the extrusion.
ZKHCSS1 Trim Kit (For 1/4" Panels)
Tubular Stainless Steel Handles
• Tape extrusion to panel to prevent movement.
• Place panel on plywood section, appearance side
down. Be sure plywood is clean without nicks and
burrs. Center punch at each screw hole location.
• Drill 1/8" pilot hole. Use 9/32" bit to enlarge clearance
hole.
• Measure and cut a 2" wide strip, top to bottom off the
corrugated panels. This will allow room for spacer
rings between the stainless panel and extrusion.
Freezer drawer:
• Place supplied filler panel (corrugated) on floor to use
as a pad.
• On the back side of the panel - at the handle end,
slip panel into the new extrusion, even end to end.
• Mark each screw hole location with pencil.
• Follow the same procedure as for fresh food door.
Screw
Decorator
Door Panel
Screw
Allen Wrench
Handle
34
