Step 2
Locate
handle
positions
Fresh food door:
• Slide custom panel into the door trim.
• Temporarily secure the new handle extrusion to the
• The custom handles must be located 3/4" to 1-1/2"
Freezer drawer:
• Slide custom panel into the freezer drawer trim.
• Temporarily secure the new handle extrusion to the
• The handle must be located 3/4" to 1-1/2" from the
• Determine the location of the custom handle and
• Drill 1/16" pilot hole through the panel until it starts
door using at least 2 screws.
from the edge of the extrusion.
Install
2 Screws
drawer using at least 2 screws.
edge of the extrusion.
carefully mark centerlines of the screw holes.
into the aluminum extrusion. This will mark the
matching location for drilling clearance holes when
assembling the handle, panel and extrusion.
ZKHC1 Trim Kit (for 1/4" Panels)
Support for custom handles
3/4" Min.
1-1/2" Max.
• Determine the desired location of the custom handle
and mark centerlines of the screw holes.
• Drill 1/16" pilot hole through the panel until it starts
into the aluminum extrusion. This will mark the
matching location for drilling the clearance hole when
assembling the handle, panel and extrusion.
3/4" Min.
1-1/2" Max.
